Winslow Straight Through Hole Mount 2.54 mm Pitch IC Socket Adapter QFN to DIP W13095RC
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Winslow |
| Orientation | Straight |
| Model | W13095RC |
| Mount Type | Through Hole |
| Housing Material | Fibreglass |
| Contact Material | Brass |
| Pitch | 2.54mm |
| Connection Gender A | Female |
| Number of Contacts A | 16 |
| Connection Gender B | Male |
| Connection A | QFN |
| Connection B | DIP |
Key Features
- This adapter converts Dual-Flat No-Leads and Quad-Flat No-Leads packages to DIP format with 2.54 mm pitch.
- Features 16 female contacts on QFN side and 16 male contacts on DIP side for secure connections.
- Through hole mount type ensures reliable PCB installation with straight orientation.
- Contacts made of brass provide durable and efficient electrical conductivity.
- Fibreglass housing ensures mechanical strength and stable insulation.
- Manufactured in the United Kingdom reflecting high-quality standards.
- Ideal for developers reducing redesign costs when switching IC packages.
Product Description
Winslow W13095RC Straight Through Hole Mount IC Socket Adapter provides an effective solution for converting Quad-Flat No-Leads (QFN) packages to Dual In Line Package (DIP) format using a precise 2.54 mm pitch.
This adapter features 16 female contacts connecting to QFN and 16 male contacts for DIP, facilitating seamless integration between different IC package types on PCBs.
Constructed with brass contacts for optimal conductivity and durability, combined with a fibreglass housing to ensure mechanical stability and electrical safety, it supports through hole mounting with a straight orientation for a secure and straightforward assembly.
The product is manufactured in the United Kingdom, reflecting stringent quality standards despite lacking specific certification approvals.
Widely used in electronics development and prototyping, these IC Socket Adapters reduce redesign costs by enabling the use of multiple package types without the need for new PCB layouts.
This adapter converts Dual-Flat and Quad-Flat No-Leads packages to DIP format with 2.54 mm pitch. Equipped with 16 female contacts on QFN side and 16 male contacts on DIP side for accurate pin alignment. Designed for through hole mounting with straight orientation for robust circuit board integration.
Durable brass contacts provide reliable conductivity. Fibreglass housing offers mechanical strength and insulation. Manufactured in the United Kingdom, ensuring reliable build quality. Ideal for industrial, manufacturing, electronic prototyping, and laboratory applications.
Explore more IC Socket Adapters and related electronic components at EnvMart for your development and manufacturing needs.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this adapter is 2.54 mm, allowing for compatibility with various Dual-Flat and Quad-Flat No-Leads packages.
The QFN side of the Winslow W13095RC adapter features 16 female contacts for connecting to the IC package.
This model supports through hole mounting with a straight orientation, ensuring secure installation on PCBs.
The contacts are made of brass for optimal conductivity, while the housing is constructed from fibreglass for mechanical strength and insulation.
The DIP side of the Winslow W13095RC adapter features 16 male contacts for secure connection to the circuit board.
This adapter is manufactured in the United Kingdom, reflecting high-quality standards in its production.
It converts Quad-Flat No-Leads (QFN) packages to Dual In Line Package (DIP) format, facilitating integration between different IC types.
The Winslow W13095RC adapter reduces the need for redesigning new PCB layouts, making it beneficial for prototyping and development.
The total number of contacts on the Winslow W13095RC adapter is 32, with 16 on the QFN side and 16 on the DIP side.
The contacts on this model are oriented straight, which aids in the straightforward assembly on circuit boards.
This adapter is suitable for industrial, manufacturing, electronic prototyping, and laboratory applications.
The product does not specify any certification approvals, but it is manufactured in the United Kingdom under stringent quality standards.
