ASSMANN WSW 1.27 mm Pitch 32 Way Surface Mount Surface PLCC IC Socket A-CCS 032-Z-SM
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 100V |
| Brand | ASSMANN WSW |
| Orientation | Straight |
| Current | 1A |
| Model | A-CCS 032-Z-SM |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | A-CCS |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 4 |
| Pitch | 1.27mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 32 |
| IC Socket Type | PLCC Socket |
| Device Mount Type | Surface |
Key Features
- Designed for surface mount device applications ensuring easy PCB integration.
- Constructed with phosphor bronze contact material for durability and excellent conductivity.
- Contact plating of tin over nickel provides corrosion resistance.
- Operates at a maximum voltage of 100 V and current of 1 A for versatile use.
- Maintains performance within a broad temperature range from -40°C to 105°C.
- Features 32 contacts arranged in 4 rows with 1.27 mm pitch for compact design.
- Housing crafted from durable nylon material for mechanical strength.
- RoHS compliant ensuring environmental safety and manufacturing standards adherence.
Product Description
ASSMANN WSW A-CCS 032-Z-SM is a high-quality 32 Way Surface Mount Surface PLCC IC Socket designed with a precise 1.27 mm pitch. Manufactured with phosphor bronze contacts and tin-over-nickel plating, this IC socket ensures reliable electrical performance and durability for electronic assemblies.
Its straight orientation and four-row contact configuration provide optimal spacing and connectivity for integrated circuits. The nylon housing material offers robust mechanical protection, suited for demanding operating environments. Operating voltage rating is 100 V with a current rating of 1 A, making it suitable for a broad range of electronic applications.
Engineered for surface mount device (SMD) mounting type, the socket supports solder termination which facilitates strong and consistent PCB assembly. It is RoHS compliant, emphasizing environmentally responsible manufacturing practices.
This IC socket supports operating temperatures ranging from -40°C to 105°C, enabling dependable operation in various industrial, electronic manufacturing, automotive, and laboratory environments.
Designed for surface mount device applications ensuring easy PCB integration. Constructed with phosphor bronze contact material for durability and excellent conductivity. Contact plating of tin over nickel provides corrosion resistance.
Operates at a maximum voltage of 100 V and current of 1 A for versatile use. Maintains performance within a broad temperature range from -40°C to 105°C. Features 32 contacts arranged in 4 rows with 1.27 mm pitch for compact design.
Housing crafted from durable nylon material for mechanical strength. RoHS compliant ensuring environmental safety and manufacturing standards adherence. Surface type termination via solder enables secure electrical connections.
Ideal for use in electronics manufacturing, communication devices, instrumentation, and industrial control systems. Explore more in the IC Socket category for compatible components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 100 V, and it can handle a current of up to 1 A.
This IC socket features a pitch size of 1.27 mm.
It has a total of 32 contacts arranged in 4 rows.
The socket uses solder termination, which facilitates secure electrical connections.
It is constructed with phosphor bronze for the contacts and has a nylon housing for mechanical strength.
The operating temperature range is from -40°C to 105°C.
Yes, this model is RoHS compliant, ensuring adherence to environmental safety standards.
The country of origin for this IC socket is Taiwan.
It is designed for surface mount device (SMD) applications, ensuring easy PCB integration.
This model is classified as a PLCC socket.
The orientation of this socket is straight.
The contacts are plated with tin over nickel, providing corrosion resistance.
