ASSMANN WSW 1.27 mm Pitch 20 Way DIP Surface PLCC IC Socket A-CCS 020-Z-SM
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 100V |
| Brand | ASSMANN WSW |
| Orientation | Straight |
| Current | 1A |
| Model | A-CCS 020-Z-SM |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | A-CCS |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 4 |
| Pitch | 1.27mm |
| Standards/Approvals | RoHS |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 20 |
| IC Socket Type | PLCC Socket |
| Device Mount Type | Surface |
Key Features
- Features 20 contact points arranged in 4 rows for reliable connections.
- Constructed with phosphor bronze contacts plated with tin over nickel for excellent conductivity.
- Designed for solder termination and surface mounting on PCBs.
- Operates within a voltage rating of 100V and current capacity of 1A.
- Housing made of durable nylon material ensuring insulation and mechanical stability.
- Supports a pitch of 1.27mm with straight orientation and 1.27mm row pitch.
- Operates safely within temperature range of -40°C to 105°C.
- Compliance with RoHS standards ensuring environmental safety.
Product Description
ASSMANN WSW A-CCS 020-Z-SM is a 20 Way DIP Surface PLCC IC Socket designed for reliable surface mounting applications in electronics manufacturing. Featuring a 1.27 mm pitch, this IC socket facilitates high density PCB layouts with efficient contact arrangements.
The IC socket incorporates phosphor bronze contact material with tin over nickel plating to ensure robust electrical conductivity and excellent corrosion resistance. Its nylon housing provides durable insulation and mechanical strength, suitable for industrial and commercial electronics assemblies.
This component supports a current rating of 1A and a voltage rating of 100V, operating within a temperature range of -40°C to 105°C, making it ideal for standard electronic devices requiring dependable socket connections. The socket termination type is solder, enabling secure surface mount placement on printed circuit boards.
Certified under RoHS standards, the product offers environmentally compliant manufacturing ensuring minimal hazardous substances. It belongs to the A-CCS series, guaranteeing consistency and quality across the product line.
Applications for this 20 way PLCC IC socket include industrial electronics, laboratory instrumentation, communication equipment, and other electronics requiring replaceable IC sockets for ease of maintenance and upgrade.
Features 20 contact points arranged in 4 rows for reliable connections. Constructed with phosphor bronze contacts plated with tin over nickel for excellent conductivity. Designed for solder termination and surface mounting on PCBs.
Operates within a voltage rating of 100V and current capacity of 1A. Housing made of durable nylon material ensuring insulation and mechanical stability. Supports a pitch of 1.27mm with straight orientation and 1.27mm row pitch.
Operates safely within temperature range of -40°C to 105°C. Compliance with RoHS standards ensuring environmental safety. Series: A-CCS, providing compatibility and high quality PLCC socket solutions. Explore more IC Sockets and components from the ASSMANN WSW series at EnvMart for your electronics manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this IC socket is 1.27 mm, which supports high-density PCB layouts.
This model has a current rating of 1A and a voltage rating of 100V, suitable for standard electronic applications.
The socket is constructed with phosphor bronze contacts plated with tin over nickel for conductivity, and its housing is made of durable nylon for insulation and mechanical stability.
It operates safely within a temperature range of -40°C to 105°C, making it suitable for various environments.
This IC socket features 20 contact points arranged in 4 rows for reliable connections.
The termination type for this socket is solder, designed for secure surface mounting on printed circuit boards.
Yes, it is certified under RoHS standards, ensuring compliance with environmental safety regulations.
This model has a straight orientation, which is standard for DIP sockets.
The housing of this socket is made from nylon, providing insulation and mechanical stability.
This model is suitable for applications in industrial electronics, laboratory instrumentation, and communication equipment that require replaceable IC sockets.
The country of origin for this product is Taiwan.
This product is a PLCC socket, designed to accommodate PLCC ICs for surface mounting.
