Vishay 40 V 2 A Schottky Diode Surface Mount DO-214AC Package SSA24-E3/61T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Length | 4.6mm |
| Model | SSA24-E3/61T |
| Width | 2.9mm |
| Mount Type | Surface |
| Series | SSA24 |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 60A |
| Maximum Forward Voltage Vf | 0.49V |
Key Features
- High performance Schottky rectifier with low forward voltage drop.
- Fast switching diode suitable for low power loss applications.
- Maximum continuous forward current rated at 2 amperes.
- Peak reverse voltage of 40 volts ensuring safe operation in switching circuits.
- Compact DO-214AC package with length of 4.6 mm and width of 2.9 mm.
- Wide operating temperature range from -65°C to 150°C.
- Low peak reverse current of 200 microamperes for efficiency.
- Peak non-repetitive forward surge current rating of 60 amperes.
Product Description
Vishay SSA24-E3/61T is a high performance Schottky diode designed for industrial electronic applications. It operates at a maximum continuous forward current of 2 amperes and withstands peak reverse voltages up to 40 volts. Its surface mount DO-214AC package measures 4.6 mm in length and 2.9 mm in width, making it compact for modern PCB designs.
This Schottky rectifier features a very low forward voltage drop of 0.49 V and extremely fast switching times, allowing efficient power conversion with minimal losses. The diode is rated for operation across a broad temperature range from -65°C up to 150°C, ensuring reliable performance under harsh industrial conditions.
The device offers a peak non-repetitive forward surge current capability of 60 A, suited for transient current spikes, and exhibits a low peak reverse leakage current of just 200 μA, enhancing energy efficiency. Its single diode configuration with two pins is ideal for surface mount technology (SMT) assembly methods.
Applications for the Vishay SSA24-E3/61T include power management, switching power supplies, automotive electronics (not certified for automotive), industrial control systems, and general-purpose rectification tasks where high efficiency and fast switching are critical.
High performance Schottky rectifier with low forward voltage drop. Fast switching diode suitable for low power loss applications. Maximum continuous forward current rated at 2 amperes. Peak reverse voltage of 40 volts ensuring safe operation in switching circuits.
Compact DO-214AC package with length of 4.6 mm and width of 2.9 mm. Wide operating temperature range from -65°C to 150°C. Low peak reverse current of 200 microamperes for efficiency. Peak non-repetitive forward surge current rating of 60 amperes.
Single diode configuration with 2 pins suitable for surface mounting. Non-automotive standard approved component, ideal for industrial applications.
Explore the Vishay range for more semiconductor components optimized for power efficiency, durability, and advanced electronic designs. Browse EnvMart’s semiconductor offerings for Schottky diodes, rectifiers, and other discrete components.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is rated at 2 amperes.
The DO-214AC package measures 4.6 mm in length and 2.9 mm in width.
This model operates within a wide temperature range from -65°C to 150°C.
The diode can handle a peak non-repetitive forward surge current of 60 amperes.
It features a low forward voltage drop of 0.49 volts.
This model has a single diode configuration with 2 pins, suitable for surface mounting.
It is suitable for applications such as power management, switching power supplies, and industrial control systems.
This unit is a Schottky rectifier, known for its fast switching capabilities and low power loss.
The Vishay SSA24-E3/61T is manufactured in India.
This model belongs to the SSA24 series of Schottky diodes.
