onsemi Bridge Rectifier 200 V 50 A Surface Mount 4-Pin Single Configuration DF02S
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2.6mm |
| Length | 8.51mm |
| Model | DF02S |
| Width | 6.5mm |
| Mount Type | Surface |
| Series | DF-S |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | SDIP |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Forward Current If | 1.5A |
| Peak Forward Voltage Vf | 1.1V |
Key Features
- The DF02S is suitable for PCB mounting with a compact SDIP package type.
- It operates reliably within a temperature range from -55°C to 150°C.
- The peak forward voltage is 1.1 V, enabling efficient rectification.
- The device supports a forward current of 1.5 A and surge current capacity up to 50 A.
- Its glass passivated chip junction design ensures low DC reverse current and high reliability.
- The pin count is 4, with a single phase bridge rectifier configuration.
- Physical dimensions include a length of 8.51 mm, width of 6.5 mm, and height of 2.6 mm.
- This product is classified as new condition and suitable for industrial and electronic semiconductor applications.
Product Description
onsemi DF02S Bridge Rectifier is a high-performance semiconductor device designed for surface mount PCB applications. It provides a peak reverse repetitive voltage rating of 200 V and a forward current capacity of 1.5 A, making it ideal for power rectification in various electronic devices and circuits.
Crafted in an SDIP package with 4 pins, the DF02S ensures easy PCB integration and reliable mechanical stability. Its single-phase configuration supports efficient conversion of AC to DC current, vital for power supply and electronic control systems.
This bridge rectifier operates within a temperature window from -55°C minimum to 150°C maximum, tolerating harsh operating environments typical in industrial and commercial electronics. The device features a low peak forward voltage of 1.1 V, which minimizes power loss during conduction and enhances overall system efficiency.
The glass passivated chip junction and low DC reverse current reduce leakage, thereby improving durability and performance. Surge current capability of 50 A allows the device to handle transient overloads without failure, making it robust under fluctuating conditions.
The DF02S package is compact with dimensions 8.51 mm length, 6.5 mm width, and 2.6 mm height. Designed specifically for surface mount technology (SMT), enabling automated assembly lines and production efficiency. Suitable applications include industrial electronics, power supplies, electronic instruments, and other semiconductor-dependent equipment.
New product condition, authentic onsemi brand quality assurance. The device complies with no specific automotive standards but adheres to industry quality and reliability norms.
Explore our comprehensive range of semiconductor components at EnvMart for trusted electronic parts that meet your laboratory, industrial manufacturing, and commercial project needs.
Explore more products in our Bridge Rectifier Module category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The DF02S has a peak reverse repetitive voltage rating of 200 V.
This model supports a forward current capacity of 1.5 A.
It can handle a peak non-repetitive forward surge current of up to 50 A.
The dimensions of this unit are 8.51 mm in length, 6.5 mm in width, and 2.6 mm in height.
It operates reliably within a temperature range from -55°C to 150°C.
This bridge rectifier is packaged in an SDIP type, suitable for surface mount applications.
It features a pin count of 4 in a single-phase configuration.
The peak forward voltage for the DF02S is 1.1 V, which aids in efficient rectification.
The DF02S is designed with a single-phase bridge rectifier configuration.
It is suitable for use in industrial electronics, power supplies, and electronic instruments.
The peak reverse current for this model is rated at 500 μA.
The DF02S is manufactured in India.
