Vishay Bridge Rectifier 1000V 500A 4-Pin D-34 Screw Mount Single VS-36MB100A

Vishay VS-36MB100A Bridge Rectifier is a high-performance power electronic component engineered to convert alternating current (AC) input to direct current (DC) output for demanding industrial, power supply, and automation applications. With a peak reverse repetitive voltage rating of 1000V and maximum forward current of 35A, this bridge rectifier provides robust performance and reliability in high-voltage environments.

This model features a four-pin, single-phase bridge configuration and comes housed in a compact D-34 screw-mount package. The device supports multiple connection methods - push-on, wrap around, or solder - for versatile integration into new or existing systems. Its insulated, high thermal conductivity case helps ensure longevity, consistent power delivery, and optimal heat dissipation, even under high load conditions.

The VS-36MB100A supports peak non-repetitive forward surge currents up to 500A, making it ideal for applications involving load peaks or start-up transients. It offers a maximum operating temperature of 150°C and minimum of -55°C, covering a wide range of industrial environmental conditions. Peak forward voltage is specified at 1.14V, and the device maintains very low leakage currents (10μA), crucial for energy efficiency and safety.

Rated 1000V peak reverse repetitive voltage for high-voltage power systems. Handles sustained forward current of 35A and peaks up to 500A during transients. Compact 28.5mm x 28.5mm footprint and 9.8mm height for flexible installation, even in space-constrained designs.

Center-hole fixing provides excellent structural support for mechanical stability. Single-phase bridge configuration suited to full-wave rectification in rectifiers or power conversion equipment. Suitable for industrial automation, electric drives, motor control, HVAC power supplies, and laboratory equipment.

Complies with rigorous industrial standards for reliability and safety.

This bridge rectifier is widely adopted in sectors such as manufacturing, HVAC systems, renewable energy, laboratory instrumentation, and other commercial setups requiring robust AC-DC conversion modules. Clear markings, standardized terminals, and Vishay's established component quality further ensure trustworthy, high-performance results in professional applications.

Explore more rectifier modules and power semiconductors from Vishay and related Bridge Rectifier Module categories on EnvMart for your next electronic system design or upgrade.
