Vishay 30 V 200 mA Surface Mount Schottky Diode 2-Pin MiniMELF LL42-GS08
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 1.6mm |
| Length | 3.7mm |
| Model | LL42-GS08 |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | LL42 |
| Maximum Operating Temperature | 125°C |
| Package Type | MiniMELF |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500nA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 4A |
| Maximum Forward Voltage Vf | 400V |
| Peak Reverse Recovery Time trr | 5ns |
Key Features
- The device features a MiniMELF package for compact PCB design.
- Maximum continuous forward current is 200 mA, ensuring efficient low power operation.
- Peak reverse repetitive voltage of 30 V protects circuits from voltage spikes.
- Extremely fast switching with a peak reverse recovery time of 5 ns.
- Wide operating temperature range from -55°C up to 125°C for varied environments.
- Low forward voltage drop reduces power loss in rectification circuits.
- 2-pin configuration supports simple integration into electronic systems.
- Package dimensions approx. 3.7 mm length and 1.6 mm width and height.
Product Description
Vishay LL42-GS08 is a high-performance 2-pin Schottky diode in a MiniMELF surface mount package designed for use in electronics requiring fast switching and low forward voltage drop. Operating at a continuous forward current of 200 mA and a peak reverse repetitive voltage of 30 V, this diode is ideal for power management and switching applications in industrial, commercial, and consumer electronics.
The diode exhibits extremely fast peak reverse recovery time of 5 ns, reducing switching losses and improving circuit efficiency. It supports a wide operating temperature range from -55°C to 125°C, making it suitable for harsh industrial or automotive environments where thermal stability is critical.
The compact MiniMELF package (3.7 mm length by 1.6 mm width and height) is designed for efficient PCB layout and mechanical stability. The device’s low forward voltage drop minimizes power dissipation, enhancing energy efficiency in rectification circuits and power supplies.
The MiniMELF package enables reliable surface mount attachment and space-saving design. Maximum forward voltage (Vf) is rated at 400 V. Peak non-repetitive forward surge current (Ifsm) is 4 A, allowing transient load tolerance.
Peak reverse current (Ir) is low at 500 nA, reducing leakage current losses. The product is suitable for application in industrial power supplies, switching regulators, and other semiconductor electronic components. The diode is compliant with standard technical specifications but has no specific certifications listed.
Manufactured in China, the product maintains consistent quality under Vishay brand standards.
This Schottky diode is a versatile semiconductor component preferred for applications requiring high efficiency and fast switching speed. It is well suited for use in power supplies, switching circuits, voltage clamping, and signal detection within industrial, laboratory, automotive, and electronics manufacturing sectors.
Search EnvMart’s semiconductor section for complementary components or alternative Vishay diode models to suit diverse application needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 200 mA, ensuring efficient low power operation.
The peak reverse repetitive voltage rating is 30 V, which protects circuits from voltage spikes.
It has an extremely fast peak reverse recovery time of 5 ns, which reduces switching losses and improves circuit efficiency.
The diode operates within a wide temperature range from -55°C to 125°C, making it suitable for various environments.
The package dimensions are approximately 3.7 mm in length and 1.6 mm in both width and height.
The peak non-repetitive forward surge current is rated at 4 A, allowing for transient load tolerance.
The maximum forward voltage (Vf) is rated at 400 V, contributing to a low forward voltage drop that minimizes power loss.
The peak reverse current is low at 500 nA, which helps reduce leakage current losses.
This diode has a 2-pin configuration, supporting simple integration into electronic systems.
It is suitable for applications in industrial power supplies, switching regulators, voltage clamping, and signal detection.
The diode is manufactured in China, maintaining consistent quality under Vishay brand standards.
This model is a Schottky rectifier, known for its fast switching and low forward voltage drop characteristics.
