Vishay 1 kV 3 A Surface Mount Switching Diode 2-Pin DO-214AA S3M-E3/57T
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | S3M-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | S3M |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 1kV |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 1.15V |
| Peak Reverse Recovery Time trr | 2.5μs |
Key Features
- Maximum continuous forward current of 3 amperes for reliable operation.
- Peak reverse repetitive voltage rating of 1 kV ensures high voltage tolerance.
- Standard recovery power diode designed for switching applications.
- Compact DO-214AA package with dimensions 7.11 mm length, 6.22 mm width, and 2.42 mm height.
- Wide operating temperature range from -55°C to 150°C for durability in harsh environments.
- Low maximum forward voltage of 1.15 V improves energy efficiency.
- Peak reverse recovery time of 2.5 microseconds supports fast switching performance.
- Complies with automotive standard AEC-Q101, suitable for automotive and industrial use.
Product Description
Vishay S3M-E3/57T is a high-efficiency standard recovery switching diode designed for electronic and power applications. Packaged in a surface mount DO-214AA case, it supports a maximum continuous forward current of 3 A and a peak reverse repetitive voltage of 1 kV, making it suitable for demanding industrial and automotive environments.
This diode features a low forward voltage of 1.15 V, reducing power loss during conduction, and a fast peak reverse recovery time of 2.5 microseconds, essential for switching circuits. The device operates reliably from -55°C to 150°C, supporting a broad range of temperature conditions.
With a compact form factor measuring 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height, the S3M-E3/57T diode simplifies PCB layout and integration into high-density electronic assemblies. Its compliance with the AEC-Q101 automotive standard further validates its ruggedness and quality for vehicular applications.
Typical applications include power rectification, switching power supplies, industrial automation systems, and automotive electronics where robust and efficient diode performance is essential.
Maximum continuous forward current of 3 amperes for reliable operation. Peak reverse repetitive voltage rating of 1 kV ensures high voltage tolerance. Standard recovery power diode designed for switching applications. Compact DO-214AA package with dimensions 7.11 mm length, 6.22 mm width, and 2.42 mm height.
Wide operating temperature range from -55°C to 150°C for durability in harsh environments. Low maximum forward voltage of 1.15 V improves energy efficiency. Peak reverse recovery time of 2.5 microseconds supports fast switching performance.
Complies with automotive standard AEC-Q101, suitable for automotive and industrial use. Single diode configuration with 2 pins simplifies PCB design and assembly. Explore more Schottky diode and rectifier options with Vishay products on EnvMart for your semiconductor and power electronics needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the S3M-E3/57T diode is 3 amperes.
This model has a peak reverse repetitive voltage rating of 1 kV, ensuring high voltage tolerance.
The diode is packaged in a DO-214AA case, with dimensions of 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
It operates reliably within a temperature range of -55°C to 150°C.
The maximum forward voltage of this model is 1.15 V, which helps improve energy efficiency.
The peak reverse recovery time for the S3M-E3/57T is 2.5 microseconds, supporting fast switching performance.
This diode complies with the AEC-Q101 automotive standard, making it suitable for automotive applications.
The S3M-E3/57T features a single diode configuration with 2 pins, simplifying PCB design and assembly.
Typical applications include power rectification, switching power supplies, industrial automation systems, and automotive electronics.
The peak non-repetitive forward surge current rating for this diode is 100 A.
The peak reverse current for the S3M-E3/57T is 10 μA.
This model is classified as a standard recovery switching diode.
