Wurth Elektronik WE-TPC 1038 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±30% 1.75 A Idc 744066470
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Operating Temperature | - 40 to +125°C |
| Height | 3.8mm |
| Length | 10mm |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | WE-TPC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Package/Case | 1038 |
| Maximum DC Current | 1.75A |
| Maximum DC Resistance | 160mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 8MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
| Standards/ApprovalsIEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, RoHS, REACH |
| IEC 60286-3 | 2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, RoHS, REACH |
Key Features
- The 1038 package case measures 10 mm in length and 3.8 mm in height and depth.
- It is designed to operate reliably at temperatures from -40°C to 125°C.
- This component has a maximum DC resistance of 160 mΩ, ensuring efficient current flow.
- The inductor construction is wirewound, optimized for surface mount technology.
- Compliance with automotive AEC-Q200 standard assures quality and reliability.
- The maximum self resonant frequency is 8 MHz, suitable for various electronic applications.
- Packaged on tape and reel for automated assembly integration.
- Its magnetic shielding reduces leakage fields, enhancing device stability.
Product Description
Wurth Elektronik model 744066470 is a magnetically shielded wirewound surface mount inductor from the WE-TPC series. It features a ferrite core design that provides 47 μH inductance with a tolerance of ±30%, suitable for handling up to 1.75 A DC current. The 1038 package case dimensions are 10 mm length, 3.8 mm height, and 10 mm depth, designed for surface mount technology (SMT).
Operating temperature ranges from -40°C to 125°C, making it suitable for automotive and industrial applications. The maximum DC resistance of 160 mΩ ensures low power loss, while the inductance and shielding characteristics minimize electromagnetic interference through magnetic shielding.
The inductor supports a maximum self resonant frequency of 8 MHz, facilitating its use in high-frequency power conversion circuits including portable power devices, DC/DC converters, embedded PCs, and telemetric systems.
This component complies with automotive AEC-Q200 standard and multiple international certifications such as IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, RoHS, and REACH, underscoring its reliability and environmental safety standards.
Packaged on tape and reel, this surface mount inductor is ready for automated manufacturing processes, enhancing production efficiency in electronics assembly lines. The 1038 case ensures compact integration in modern electronic devices.
Ferrite core and wirewound construction provide stable inductance characteristic. Magnetic shielding reduces leakage and interference in sensitive circuits. The component is ideal for use in portable electronics, automotive electronics, and power management systems.
Manufactured in China under strict quality controls for consistency and performance. Explore our wide range of Surface Mount Inductors and other electronic components at EnvMart for your project and production needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 47 μH with a tolerance of ±30%.
It can handle a maximum DC current of 1.75 A.
The 1038 package case measures 10 mm in length, 10 mm in depth, and 3.8 mm in height.
The operating temperature range is from -40°C to +125°C.
The maximum DC resistance is 160 mΩ, ensuring efficient current flow.
The maximum self resonant frequency is 8 MHz.
It complies with automotive AEC-Q200 and multiple international standards including IEC 60286-3:2013, IEC 61249-2-21, IPC/JEDEC J-STD-020E, JEDEC JS709B, RoHS, and REACH.
It is packaged on tape and reel, which facilitates automated assembly integration.
The inductor features a wirewound construction optimized for surface mount technology.
The core material is ferrite, which contributes to its magnetic shielding properties.
It is suitable for various electronic applications, including portable power devices, DC/DC converters, embedded PCs, and telemetric systems.
The termination style is surface mount, designed for easy integration into electronic circuits.
