DiodesZetex Type P-Channel MOSFET, 900 mA Continuous Drain Current, 20 V Drain Source Voltage, 3-Pin SOT-23 ZXM61P02FTA

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex Type P-Channel MOSFET, 900 mA Continuous Drain Current, 20 V Drain Source Voltage, 3-Pin SOT-23 ZXM61P02FTA

Name: DiodesZetex Type P-Channel MOSFET, 900 mA Continuous Drain Current, 20 V Drain Source Voltage, 3-Pin SOT-23 ZXM61P02FTA
Brand: DiodesZetex
SKU: 394592
Price: 20.22 USD
Availability: InStock



Category MOSFET Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	1mm
Length	3.05mm
Model	ZXM61P02FTA
Width	1.4mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Automotive Standard	AEC-Q101
Channel Type	Type P
Maximum Continuous Drain Current Id	900mA
Maximum Drain Source Voltage Vds	20V
Maximum Drain Source Resistance Rds	900mΩ
Channel Mode	Enhancement
Maximum Power Dissipation Pd	806mW
Typical Gate Charge Qg @ Vgs	3.5nC
Maximum Gate Source Voltage Vgs	-12, +12V
Forward Voltage Vf	-0.95V

Key Features

This transistor features an enhancement mode channel for reliable switching applications.
The device supports a maximum power dissipation of 806 mW for efficient heat management.
It has a maximum drain-source resistance of 900 mΩ, ensuring low conduction losses.
The MOSFET operates within a wide temperature range from -55°C to 150°C for industrial robustness.
A gate charge of 3.5 nC supports fast switching performance at a gate voltage of 3.5 V.
Forward voltage is measured at -0.95 V, contributing to power efficiency.
Package dimensions include a length of 3.05 mm, width of 1.4 mm, and height of 1 mm.
Constructed to automotive standard AEC-Q101 for high reliability in vehicle electronics.

Product Description

The DiodesZetex ZXM61P02FTA is a P-Channel MOSFET designed for use in electronic circuits requiring efficient switching with up to 900 mA continuous drain current and a maximum drain-source voltage of 20 V. Housed in a surface-mount SOT-23 3-pin package, this device provides a compact solution for space-constrained PCB layouts.

The enhancement mode channel allows for precise control and fast response times, suitable for applications in power management, switching regulators, and load switching in industrial and automotive sectors. Its maximum power dissipation rating of 806 mW ensures stable performance under typical operating conditions.

Designed to tolerate a broad operating temperature range from -55°C to 150°C, it fits well in harsh environments including automotive electronics, industrial machinery, and consumer electronics. The maximum drain-source resistance of 900 mΩ aids in reducing conduction losses, improving energy efficiency.

The device features a low typical gate charge of 3.5 nC at a gate-source voltage of 3.5 V, allowing for quick switching speeds necessary in modern electronic control systems. Forward voltage is rated at -0.95 V, further ensuring efficient power delivery.

The compact SOT-23 package has dimensions of 3.05 mm in length, 1.4 mm in width, and 1 mm in height, enabling easy integration onto compact PCBs. Compliance with the automotive AEC-Q101 standard confirms its robustness for use in automotive electronics applications demanding high reliability.

This MOSFET is ideal for industrial, automotive, and consumer electronic applications requiring low power switching and load control. It benefits power supply circuits, battery management systems, and signal switching modules.

DiodesZetex ensures quality manufacturing with adherence to industry standards for enhanced durability and performance. Explore more DiodesZetex MOSFETs and electronic components on EnvMart for your circuit design and industrial needs.
