Wurth Elektronik 2.4 V Red LED PLCC 4 Surface Mount High Luminosity Dome Lens WL-SMTD 150141RS66130
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Model | 150141RS66130 |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Series | WL-SMTD |
| Maximum forward current | 70mA |
| Viewing angle | 60 ° |
| Package Type | PLCC 4 |
| Lens Colour | Red |
| Standards/Approvals | REACH, IEC 61249-2-21, RoHS, IEC-62471 |
| LED Colour | Red |
| Dominant Wavelength | 620nm |
| Forward Voltage | 2.4V |
| Number of Pins | 2 |
| LED Luminosity | 5500 mcd |
| Maximum Power Dissipation | 196mW |
| Lens Dimensions | 3.5 x 2.8 x 3.5 mm |
| Lens Shape | Dome |
| Lens Finish | Diffused |
Key Features
- Features a diffused dome lens with 3.5 x 2.8 x 3.5 mm dimensions.
- Utilizes AlInGaP chip technology for efficient red light emission.
- Has a viewing angle of 60 degrees for wide light dispersion.
- Rated for a maximum forward current of 70 mA and power dissipation of 196 mW.
- Compatible with IR soldering processes for surface mounting.
- Operates reliably between -40°C and +100°C ambient temperatures.
- Ideal for use in traffic signals, backlighting, push buttons, and navigation systems.
- Complies with REACH, IEC 61249-2-21, RoHS, and IEC-62471 standards.
Product Description
Wurth Elektronik 150141RS66130 is a red LED component with a 2.4 V forward voltage and surface mount package type PLCC 4. This LED features a diffused dome lens measuring 3.5 x 2.8 x 3.5 mm, employing AlInGaP chip technology to deliver high brightness light emission with a luminous intensity of 5500 mcd. The viewing angle is 60 degrees, which ensures effective light dispersion for a variety of industrial and commercial applications.
This LED is rated for a maximum forward current of 70 mA and maximum power dissipation of 196 mW, making it suitable for robust electronic designs. It supports tape and reel packaging, facilitating automated surface mount assembly using IR soldering methods.
Operating temperature ranges from -40 up to +100 degrees Celsius, ensuring durability in harsh environments. The dome lens features a diffused finish and red color, optimized for visual signaling applications.
Typical use cases include traffic light systems, backlighting in control panels, cabin or push button indicators, as well as navigation and audio systems. The component meets industry standards such as REACH, IEC 61249-2-21, RoHS compliance, and IEC-62471 for photobiological safety.
Wurth Elektronik LEDs like the 150141RS66130 are known for their high optical efficiency and reliability, supporting various electronics manufacturing and industrial applications. This model forms part of the WL-SMTD series offering consistent performance in demanding lighting environments.
Features a diffused dome lens with 3.5 x 2.8 x 3.5 mm dimensions. Utilizes AlInGaP chip technology for efficient red light emission. Has a viewing angle of 60 degrees for wide light dispersion. Rated for a maximum forward current of 70 mA and power dissipation of 196 mW.
Compatible with IR soldering processes for surface mounting. Operates reliably between -40°C and +100°C ambient temperatures. Ideal for use in traffic signals, backlighting, push buttons, and navigation systems. Complies with REACH, IEC 61249-2-21, RoHS, and IEC-62471 standards.
Explore Wurth Elektronik products and other electronic components in the LEDs category on EnvMart for your industrial and commercial lighting solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The forward voltage of this red LED is 2.4 V.
This model is rated for a maximum forward current of 70 mA.
The lens dimensions are 3.5 x 2.8 x 3.5 mm.
The viewing angle of this LED is 60 degrees, allowing for wide light dispersion.
The luminous intensity of this LED is 5500 mcd.
This model has a maximum power dissipation of 196 mW.
This LED supports surface mounting and is compatible with IR soldering processes.
This LED complies with REACH, IEC 61249-2-21, RoHS, and IEC-62471 standards.
It operates reliably between -40°C and +100°C ambient temperatures.
This LED is packaged in tape and reel format, facilitating automated assembly.
This LED is ideal for use in traffic signals, backlighting, push buttons, and navigation systems.
This model utilizes AlInGaP chip technology for efficient red light emission.
