Vishay Schottky Diode 90 V 1.5 A Surface Mount DO-214AC BYS12-90-E3/TR

Free Delivery in India | Lowest Global Shipping Charges

Vishay Schottky Diode 90 V 1.5 A Surface Mount DO-214AC BYS12-90-E3/TR

Name: Vishay Schottky Diode 90 V 1.5 A Surface Mount DO-214AC BYS12-90-E3/TR
Brand: Vishay
SKU: 376113
Price: 0.27 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand Vishay Condition New

Specifications

Country of Origin	China
Brand	Vishay
Height	2.09mm
Length	4.5mm
Model	BYS12-90-E3/TR
Width	2.79mm
Mount Type	Surface
Series	BYS12-90
Maximum Operating Temperature	150°C
Package Type	DO-214AC
Minimum Operating Temperature	-55°C
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	1.5A
Peak Reverse Repetitive Voltage Vrrm	90V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	1mA
Peak Non-Repetitive Forward Surge Current Ifsm	40A
Maximum Forward Voltage Vf	360mV

Key Features

Surface mount type with DO-214AC package for easy PCB integration.
Maximum continuous forward current of 1.5 A ensuring robust current handling.
Peak reverse repetitive voltage rated at 90 V for reliable performance.
Extremely low forward voltage drop of 360 mV minimizes power loss.
Qualified to automotive standard AEC-Q101 for high reliability applications.
Fast switching Schottky rectifier suitable for power and high-frequency circuits.
Wide operating temperature range from -55°C to 150°C for versatile use.
2-pin single diode configuration for simplified circuit design.

Product Description

Vishay BYS12-90-E3/TR is a high-performance Schottky diode designed for efficient rectification and fast switching in power electronic circuits. This surface mount diode features a DO-214AC package, supporting a maximum continuous forward current of 1.5 A and a peak reverse repetitive voltage of 90 V. The low forward voltage drop of approximately 360 mV helps reduce power losses and heat generation, enhancing circuit efficiency.

Manufactured under high standards with compliance to automotive grade AEC-Q101, the BYS12-90-E3/TR diode is ideal for demanding automotive, industrial, and consumer electronics applications where reliability and ruggedness are critical. Its compact size supports space-saving PCB layouts while maintaining excellent electrical performance.

Operating reliably over a wide temperature range from -55°C to +150°C, this Schottky diode is suitable for harsh environments and high-temperature applications. It exhibits fast switching capabilities and low reverse leakage current, making it suitable for power supplies, voltage clamping, and freewheeling diode applications.

Surface mount design allows ease of mounting and automated PCB assembly. High current capacity supports robust power stages and rectification duties. Schottky barrier technology ensures minimal forward voltage drop and fast switching.

Compact DO-214AC package conserves PCB space with mechanical stability. Automotive qualification solidifies reliability in strict environments.

This diode is widely used in industrial, automotive, power management, and telecommunications equipment. It enables efficient power rectification with improved system performance. Choose Vishay’s BYS12-90-E3/TR for reliable, high-efficiency Schottky diode applications.

Explore more high-quality semiconductor components and Schottky rectifiers at EnvMart's Electronics & Electricals section for advanced industrial and commercial designs.

Explore more products in our Schottky Diodes & Rectifiers category.
