onsemi Bridge Rectifier 200 V 8 A Single Phase 4-Pin Through Hole GBU8D

onsemi GBU8D Bridge Rectifier is a single-phase, 4-pin, glass passivated bridge rectifier designed for through-hole mounting applications. It features a peak reverse repetitive voltage of 200 V and a forward current rating of 8 A, making it suitable for power electronic circuits requiring efficient AC-to-DC conversion.

This device supports high surge currents with a peak non-repetitive forward surge current rating of 200 A, ensuring reliability under transient conditions. Its low peak forward voltage drop of 1 V aids in minimizing power losses during operation.

The compact dimensions of 18.8 mm height, 22.3 mm length, and 3.56 mm width help optimize space on PCBs while the component withstands a wide operating temperature range from -55°C to 150°C, suitable for harsh industrial and commercial environments.

The bridge rectifier is ideal for use in industrial, laboratory, electronic component manufacturing, power supplies, and various semiconductor applications. The GBU package simplifies PCB assembly and provides robust mechanical stability.

High peak reverse repetitive voltage rating of 200 volts. Forward current capacity of 8 amperes for reliable power rectification. Peak non-repetitive forward surge current up to 200 amperes. Compact dimensions enable efficient PCB design implementation.

Wide operating temperature range allows deployment in industrial settings. Glass passivated construction enhances device longevity and performance. Through-hole mounting type facilitates secure PCB assembly. Single-phase 4-pin bridge rectifier simplifies circuit design.

Low forward voltage drop optimizes electrical efficiency. It conforms to industry standards for bridge rectifiers but does not carry automotive-specific certifications. Explore additional high-quality Bridge Rectifiers and semiconductor components on EnvMart for your electronic design and manufacturing needs.
