Taiwan Semiconductor Bridge Rectifier 1000 V 208 A 4-Pin Quad TS-6PL T15JA07G-K

Free Delivery in India | Lowest Global Shipping Charges

Taiwan Semiconductor Bridge Rectifier 1000 V 208 A 4-Pin Quad TS-6PL T15JA07G-K

Name: Taiwan Semiconductor Bridge Rectifier 1000 V 208 A 4-Pin Quad TS-6PL T15JA07G-K
Brand: Taiwan Semiconductor
SKU: 405816
Price: 0.99 USD
Availability: InStock



Category Bridge Rectifier Brand Taiwan Semiconductor Condition New

Specifications

Country of Origin	India
Brand	Taiwan Semiconductor
Height	30mm
Length	29.3mm
Model	T15JA07G-K
Mount Type	Through Hole
Configuration	Quad
Maximum Operating Temperature	150°C
Package Type	TS-6PL
Minimum Operating Temperature	-55°C
Number of Phases	1
Standards/Approvals	RoHS, UL, IEC 61249-2-21
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	1000V
Peak Reverse Current Ir	0μA
Peak Non-Repetitive Forward Surge Current Ifsm	208A
Forward Current If	15A
Peak Forward Voltage Vf	1.1V

Key Features

Features a peak reverse repetitive voltage of 1000 V for high voltage tolerance.
Configured as a 4-pin quad for efficient PCB mounting and integration.
Supports a continuous forward current of 15 A with surge current capacity of 208 A.
Operates reliably across a temperature range from -55°C to 150°C.
Glass passivated chip junction ensures durability and longevity in harsh conditions.
Ideal for applications including switching mode power supplies, adapters, and lighting.
Compliant with RoHS, UL recognized, and halogen-free according to IEC 61249-2-21 standards.

Product Description

Taiwan Semiconductor T15JA07G-K Bridge Rectifier is a high-performance semiconductor device designed for reliable AC to DC power conversion. Packaged in a TS-6PL through-hole mount with a quad 4-pin configuration, it provides efficient rectification in compact form factors.

It supports a peak reverse repetitive voltage (VRRM) of 1000 V and can handle a continuous forward current (IF) of 15 A, with a peak non-repetitive forward surge current (IFSM) of 208 A, making it suitable for high power applications. The device operates safely over a wide temperature range from -55°C minimum to 150°C maximum, suitable for industrial and commercial environments.

This bridge rectifier employs a glass passivated chip junction which enhances the device's reliability and extends its service life, especially in switching mode power supply circuits (SMPS), adapter units, and lighting applications.

The rectifier is RoHS compliant, UL recognized (File # E-326243), and halogen-free per IEC 61249-2-21 standards, aligning with modern regulatory and environmental requirements. The quad configuration and through-hole mounting facilitate ease of use on printed circuit boards (PCBs) with high surge current capability and minimal power loss (peak forward voltage Vf of 1.1 V).

Peak reverse repetitive voltage: 1000 V for high voltage applications. Forward current rating supports 15 A continuous operation. Surge current capacity up to 208 A for robustness. Wide operating temperature from -55°C to 150°C ensures versatility.

RoHS, UL, and IEC certifications endorse quality and safety. Glass passivated chip junction for enhanced durability. Ideal for industrial, HVAC, manufacturing, and electronic power conversion uses.

This Taiwan Semiconductor bridge rectifier is a reliable component choice for engineers and designers seeking quality discrete semiconductors in power management and electronic circuit applications.
