onsemi Bridge Rectifier 400 V 300 A 4-Pin Single GBPC3504W

Free Delivery in India | Lowest Global Shipping Charges

onsemi Bridge Rectifier 400 V 300 A 4-Pin Single GBPC3504W

Name: onsemi Bridge Rectifier 400 V 300 A 4-Pin Single GBPC3504W
Brand: onsemi
SKU: 374086
Price: 6.07 USD
Availability: InStock



Category Bridge Rectifier Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	11.23mm
Length	29mm
Model	GBPC3504W
Width	29mm
Mount Type	Through Hole
Series	GBPC35W
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	GBPC
Minimum Operating Temperature	-55°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	400V
Peak Reverse Current Ir	500μA
Peak Non-Repetitive Forward Surge Current Ifsm	300A
Forward Current If	35A
Peak Forward Voltage Vf	1.1V

Key Features

Features peak reverse repetitive voltage of 400 V.
Supports forward current of 35 A.
Through hole mount type for easy PCB installation.
Operates under a maximum temperature of 150°C and minimum of -55°C.
Consists of 4 pins arranged in a single configuration.
Peak non-repetitive forward surge current capacity of 300 A.
Compact dimensions of 29 mm length, 29 mm width, and 11.23 mm height.
Suitable for use in power electronics and semiconductor applications.

Product Description

onsemi GBPC3504W Bridge Rectifier is a high-performance semiconductor designed for power rectification in various electronic applications. This single-phase, 4-pin bridge rectifier is rated for a peak reverse repetitive voltage of 400 V and a forward current of 35 A, making it suitable for robust industrial and commercial electronic devices.

Its through hole mounting package (GBPC) ensures secure PCB integration, while the device operates efficiently within a temperature range from -55°C to 150°C. The compact dimensions of 29 mm in length and width, with a height of 11.23 mm, allow it to fit well in space-constrained assemblies.

The GBPC3504W bridge rectifier supports a peak non-repetitive forward surge current of 300 A, ensuring durability under transient conditions. Its low peak forward voltage of 1.1 V and minimal peak reverse current of 500 μA contribute to efficient power conversion with minimal losses.

This Bridge Rectifier is part of the GBPC35W series and is manufactured to meet demanding electronic component standards for semiconductor discrete devices. It is ideal for use in power supplies, industrial control systems, automotive electronics (although no specific automotive certifications are noted), and other demanding electrical and electronic systems requiring reliable AC to DC conversion.

Features peak reverse repetitive voltage of 400 V. Supports forward current of 35 A. Through hole mount type for PCB installation. Operating temperature from -55°C to 150°C. 4-pin single-phase configuration for efficient rectification.

Peak non-repetitive forward surge current of 300 A. Compact package dimensions: 29 mm length, 29 mm width, 11.23 mm height. Peak forward voltage of 1.1 V reduces power loss. Minimal peak reverse current of 500 μA for reliable operation.

This product is new, made in India by default unless otherwise specified. It delivers dependable performance in industrial, laboratory, and electronic manufacturing environments. For further exploration, browse our Electronics & Electricals and Semiconductor categories at EnvMart.
