IXYS N-Channel IGBT Module 90 A 1200 V 7-Pin Y4-M5 Surface Mount MII75-12A3

The IXYS MII75-12A3 is a high-performance N-Channel Insulated Gate Bipolar Transistor (IGBT) Module designed for critical power switching applications. This device combines the advantages of MOSFET gate drive characteristics with the high current and low voltage drop properties of bipolar transistors, making it suitable for efficient power conversion and control.

Featuring a maximum continuous collector current (Ic) of 90A and a maximum collector emitter voltage (Vceo) of 1200V, this module is capable of handling demanding electrical loads with ease. The robust construction supports a maximum power dissipation (Pd) of 370W, allowing reliable operation under high thermal and electrical stress.

This module incorporates a 7-pin Y4-M5 surface mount package, facilitating easy integration into existing circuit designs. Its compact form factor with dimensions 94mm by 34mm and a height of 30mm ensures space-efficient installation in constrained environments.

The MII75-12A3 supports high switching speeds up to 30kHz, enabling applications in power inverters, motor drives, and industrial power supplies. It is rated for a maximum gate emitter voltage of 20 V and withstands operating temperatures ranging from -40°C to 150°C to provide thermal flexibility for various industrial environments.

Key electrical characteristics include a maximum collector emitter saturation voltage (VceSAT) of 2.7V, ensuring low conduction losses for improved efficiency. The N-channel configuration makes it optimal for high-side switching applications.

7-pin Y4-M5 surface mount package for easy PCB integration. High continuous current and voltage ratings suitable for industrial power electronics. Wide operating temperature range supporting -40°C to 150°C. Fast switching capability at 30kHz for efficient performance.

Low saturation voltage reduces heat dissipation and energy losses. Compact dimensions facilitate integration into space-limited systems. N-channel IGBT technology for excellent switching and conduction performance. Reliable under high power dissipation up to 370W.

This module is suitable for use in industrial manufacturing, automation control systems, power inverters, motor drives, and HVAC equipment where reliable and efficient switching devices are crucial. Its design optimizes both switching speed and losses, making it an excellent choice for demanding applications.
