Infineon Single IGBT Module 70A 650V AG-EASY3B FS3L100R07W3S5B11BPSA1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Height | 16.4mm |
| Length | 109.9mm |
| Model | FS3L100R07W3S5B11BPSA1 |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | AG-EASY3B |
| Minimum Operating Temperature | -40°C |
| Maximum Continuous Collector Current Ic | 70A |
| Maximum Collector Emitter Voltage Vceo | 650V |
| Maximum Collector Emitter Saturation Voltage VceSAT | 1.38V |
| Maximum Power Dissipation Pd | 20mW |
| Maximum Gate Emitter Voltage VGEO | 20 V |
| Number of Transistors | 1 |
Key Features
- Rated for 70A continuous collector current and 650V collector emitter voltage.
- Features AG-EASY3B package and single transistor configuration.
- TRENCHSTOP™ 5 technology ensures high efficiency in PV solar and industrial applications.
- Operational temperature range from -40°C to 150°C.
- Compact module with dimensions of 109.9mm length and 16.4mm height.
- Ideal for three-level NPC1 topology systems up to 40 kVA.
- PressFIT contact technology for optimal connection and reliability.
- Integrated NTC for temperature monitoring and enhanced protection.
Product Description
Infineon FS3L100R07W3S5B11BPSA1 Single IGBT Module is designed for advanced power conversion applications, providing high efficiency, reliability, and robust thermal performance in demanding environments. The module delivers a maximum continuous collector current of 70A and supports collector-emitter voltage up to 650V, making it suitable for medium to high power systems such as solar inverters, industrial drives, and power supplies.
Utilizing Infineon’s TRENCHSTOP™ 5 technology, this module achieves remarkable efficiency with low conduction and switching losses. It is commonly implemented in three-level NPC1 topology for renewable energy systems, particularly up to 40 kVA in 1000V DC PV installations. The AG-EASY3B package ensures compatibility with compact, high-density layouts and facilitates ease of integration.
With a single transistor configuration, the FS3L100R07W3S5B11BPSA1 supports simple yet powerful switching applications, while the PressFIT contact technology guarantees reliable electrical connections and rapid assembly. This module includes integrated NTC thermistor for real-time temperature sensing, providing an extra layer of operational safety.
Maximum continuous collector current: 70A for robust power handling. Collector emitter voltage: 650V supports advanced inverter design. Package type: AG-EASY3B for high-density electronics layouts. PressFIT technology enables strong, maintenance-free connections.
Integrated NTC thermistor for precise temperature monitoring. Operational temperature range: -40°C to 150°C suits demanding environments. Module dimensions: 109.9mm length, 16.4mm height for compact installation. Excellent performance in solar and industrial applications, efficiency up to 99%.
This module is widely used in industrial and commercial power conversion, renewable energy systems, and variable speed drives, where advanced efficiency and reliability are key requirements. Its innovative design helps reduce system energy losses and supports sustainable solutions.
Browse more Infineon IGBT Modules and semiconductor solutions in the EnvMart Electronics & Electricals category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous collector current of this module is 70A, making it suitable for robust power handling in various applications.
This IGBT module supports a collector-emitter voltage of up to 650V, which is essential for advanced inverter designs.
The operational temperature range for this module is from -40°C to 150°C, allowing it to function effectively in demanding environments.
It utilizes the AG-EASY3B package type, which is designed for high-density electronics layouts and ease of integration.
The PressFIT contact technology enables strong, maintenance-free connections, ensuring reliable electrical connections and rapid assembly.
The module has a height of 16.4mm and a length of 109.9mm, making it compact for installation in various applications.
It features Infineon's TRENCHSTOP™ 5 technology, which ensures high efficiency with low conduction and switching losses.
This IGBT module is commonly used in solar inverters, industrial drives, and power supplies, particularly in renewable energy systems.
The maximum gate emitter voltage for this IGBT module is 20V, which is important for its operational specifications.
Yes, it includes an integrated NTC thermistor for real-time temperature sensing, enhancing operational safety.
The maximum power dissipation for this IGBT module is 20mW, which is relevant for thermal management in applications.
This module has a single transistor configuration, which supports simple yet effective switching applications.
