Infineon Arduino Shield 4 High Side Switches Demonstration Board Rev 3 BTS7008-1EPP

Free Delivery in India | Lowest Global Shipping Charges

Infineon Arduino Shield 4 High Side Switches Demonstration Board Rev 3 BTS7008-1EPP

Name: Infineon Arduino Shield 4 High Side Switches Demonstration Board Rev 3 BTS7008-1EPP
Brand: Infineon
SKU: 431737
Price: 70.96 USD
Availability: InStock



Category Arduino Shield Brand Infineon Condition New

Specifications

Country of Origin	India
Brand	Infineon
Model	BTS7008-1EPP
For Use With	XMCTM4700 Relax Kit, XMCTM4800 Relax Kit, Arduino Uno R3, XMCTM1100 Boot Kit, Arduino Due
Kit Classification	Demonstration Board
Revision	Rev 3

Key Features

The shield allows control and protection of 12V supply outputs.
It can turn ON and OFF loads such as bulbs, heating resistors, and motor drives.
Provides load current measurement and no-load condition detection.
Features current trip protection concept with intelligent latch.
Simplifies ground network design with cost-efficient implementation.
Applications include automotive areas and flexible design across families.
Compatible with XMCTM4700 Relax Kit, XMCTM4800 Relax Kit, Arduino Uno R3, XMCTM1100 Boot Kit, and Arduino Due.
RoHS compliant green product.

Product Description

The Infineon BTS7008-1EPP Arduino Shield is a demonstration board featuring 4 high side switches providing advanced protection and diagnostic functionalities. This shield is specifically designed to demonstrate relay and fuse replacement, enabling the control and protection of outputs from a 12V supply. Its ability to turn ON or OFF various loads such as bulbs, heating resistors, and motor drives makes it versatile for multiple development applications.

The protection concept includes a current trip mechanism coupled with an intelligent latch that safeguards the connected outputs effectively. Additionally, the shield adopts a simplified and cost-efficient ground network, enhancing its applicability in automotive environments. The design is optimized for flexibility across the BTS7008 family with pin-to-pin and external component compatibility, supporting various use cases and development boards.

This demonstration board supports XMCTM4700 Relax Kit, XMCTM4800 Relax Kit, Arduino Uno R3, XMCTM1100 Boot Kit, and Arduino Due, facilitating easy integration and prototyping. As a green product, it complies with RoHS regulations, ensuring environmental standards adherence.

The shield enables control and protection of 12V supply outputs. Load ON/OFF control for bulbs, heating resistors, and motor drives. Load current measurement and no-load detection capabilities. Current trip protection with intelligent latch mechanism.

Simplified and cost-efficient ground network design. Optimized for automotive applications and flexible design compatibility. Supports multiple development kits including XMCTM and Arduino boards. RoHS compliant environment-friendly product.

This Arduino Shield is ideal for industrial and automotive electronic development, laboratory prototyping, and educational demonstrations. It provides developers with a robust platform to experiment with high side switch control, protection features, and various output load management. Explore more in EnvMart’s Electronics Components section for compatible development kits and shields.
