STMicroelectronics 200 V 15 A Diode Switching Through Hole Package TO-247 STTH3002CW
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 3.75mm |
| Brand | STMicroelectronics |
| Height | 20.15mm |
| Length | 15.75mm |
| Model | STTH3002CW |
| Width | 5.15mm |
| Mount Type | Through Hole |
| Series | STTH3002C |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 15A |
| Peak Reverse Repetitive Voltage Vrrm | 200V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 20μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 180A |
| Maximum Forward Voltage Vf | 1.18V |
| Peak Reverse Recovery Time trr | 22ns |
Key Features
- Features a 3-pin through-hole TO-247 package for easy mounting.
- Maximum continuous forward current of 15 amperes suitable for power applications.
- Peak reverse repetitive voltage of 200 volts ensures reliable isolation.
- Fast switching rectifier with a peak reverse recovery time of 22 nanoseconds.
- Operating temperature range from -65°C to 175°C for robust performance.
- Maximum forward voltage drop is 1.18 volts which optimizes efficiency.
- Supports peak non-repetitive forward surge current up to 180 amperes.
- Designed with common cathode diode configuration ideal for rectifier circuits.
Product Description
STMicroelectronics STTH3002CW is a high-performance switching diode designed for power rectification applications operating at a maximum forward current of 15 A and reverse voltage of 200 V. Packaged in a durable TO-247 through-hole type with 3 pins, this diode ensures reliable installation in various electronic circuits.
It features a fast switching rectifier characteristic with a swift peak reverse recovery time of 22 nanoseconds, making it suitable for high-frequency applications in power supplies, inverters, and motor control systems. The diode’s maximum forward voltage drop of 1.18 V contributes to enhanced efficiency by minimizing conduction losses.
Designed to operate in wide temperature ranges from -65°C to 175°C, the diode withstands harsh industrial and automotive environments. Its peak non-repetitive surge current rating of 180 A provides robustness against transient loads.
Compliant with RoHS standards, the STTH3002CW supports environmentally responsible manufacturing. Physical dimensions include a height of 20.15 mm, length of 15.75 mm, width of 5.15 mm, and a pin diameter of approximately 3.75 mm, facilitating integration into power electronics.
3-pin TO-247 through-hole package suitable for high-power switching applications. Maximum continuous forward current of 15 A supports demanding load requirements. Peak reverse repetitive voltage of 200 V ensures device reliability.
Fast recovery time of 22 ns allows for efficient switching performance. Wide operating temperature range (-65°C to 175°C) for versatility. Low forward voltage drop of 1.18 V helps reduce power losses. High surge current capacity of 180 A provides durability against spikes.
Common cathode diode configuration ideal for rectifier circuits. RoHS compliant for environmentally friendly applications. Compact physical dimensions enable easy integration.
This diode is commonly used in power rectification for industrial, electronic, and automotive applications. It is ideal for circuit designs needing high efficiency and durability at elevated temperatures.
Explore more semiconductor components at EnvMart for your project and industrial needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the STMicroelectronics STTH3002CW diode is 15 A, making it suitable for power applications.
This model has a peak reverse repetitive voltage rating of 200 V, ensuring reliable isolation in various applications.
The STTH3002CW features a peak reverse recovery time of 22 nanoseconds, allowing for efficient switching performance in high-frequency applications.
The diode operates within a wide temperature range from -65°C to 175°C, making it versatile for harsh environments.
The maximum forward voltage drop for the STTH3002CW is 1.18 V, which helps to optimize efficiency by minimizing conduction losses.
It supports a peak non-repetitive forward surge current of up to 180 A, providing robustness against transient loads.
The STTH3002CW is packaged in a TO-247 through-hole type with 3 pins, facilitating easy mounting in electronic circuits.
The pin diameter of the STTH3002CW is approximately 3.75 mm, which aids in its integration into various applications.
This diode is designed with a common cathode configuration, making it ideal for rectifier circuits.
Yes, the STTH3002CW is compliant with RoHS standards, supporting environmentally responsible manufacturing practices.
The physical dimensions of this diode are 20.15 mm in height, 15.75 mm in length, and 5.15 mm in width.
The STTH3002CW is commonly used in power rectification for industrial, electronic, and automotive applications, particularly where high efficiency is needed.
