Texas Instruments 4 2-Input XOR Logic Gate, 14-Pin PDIP SN74HC86N

Texas Instruments SN74HC86N is a 4 2-Input XOR Logic Gate integrated circuit enclosed in a 14-Pin PDIP package. This logic gate IC utilizes high-speed CMOS technology providing efficient logic operation with low power consumption, making it suitable for various electronic and semiconductor applications.

Designed for through-hole mount, it supports a supply voltage from 2 V to 6 V, making it versatile for different operating conditions. The IC delivers fast signal processing with a maximum propagation delay time of 25 ns, ensuring prompt logic responses in circuits.

The device hosts four independent 2-input XOR gates, each operating with CMOS input and output compatibility, which provides flexibility in digital logic design. Its robust operating temperature range of -40°C to 85°C allows it to function reliably in demanding industrial and commercial environments.

The SN74HC86N is a member of the 74HC family and features a push-pull output type with 14 pins, ensuring straightforward integration into printed circuit boards with through-hole technology. It does not include Schmitt Trigger inputs and is not designed specifically for automotive standards.

Four independent 2-input XOR gates per IC. High-speed CMOS logic family. Wide operating voltage range from 2 to 6 volts. Push-pull output configuration suitable for various logic levels. Robust operating temperature range from -40°C to 85°C.

Through-hole PDIP package with 14 pins for easy PCB mounting. Manufactured in Malaysia adhering to quality standards. Compatible with CMOS input and output logic signals. Maximum propagation delay of 25ns at specified load conditions.

Ideal for industrial, laboratory, and commercial electronic design applications.

This Texas Instruments SN74HC86N logic gate is perfectly suited for use in electronic circuit design, semiconductor applications, laboratory instruments, and industrial automation where reliable high-speed XOR logic is required. Its compact size and industry-standard pin configuration make it a preferred choice for integrated circuit designers and engineers.

EnvMart offers this premium Texas Instruments SN74HC86N 4 2-Input XOR Logic Gate for professionals seeking high-quality electronic components for efficient logic implementations in semiconductors and electronic products.
