Vishay 60 V 1 A Surface Mount Schottky Barrier Diode 2-Pin DO-214AC SS16-E3/5AT
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 2.29mm |
| Length | 4.6mm |
| Model | SS16-E3/5AT |
| Width | 2.9mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 40A |
| Maximum Forward Voltage Vf | 0.75V |
Key Features
- Features a low forward voltage drop for reduced power loss.
- Incorporates an over-voltage protection guard ring.
- High efficiency with low power dissipation.
- Suitable for surface mount applications in compact PCB designs.
- Operating temperature ranges from -65°C to 150°C ensuring reliability in harsh environments.
- Has a maximum continuous forward current of 1 A and peak non-repetitive surge current of 40 A.
- Utilized in low voltage inverters, freewheeling diodes, DC/DC converters, and polarity protection circuits.
Product Description
Vishay SS16-E3/5AT is a high-performance Schottky barrier rectifier diode designed for surface mount technology, housed within a low-profile DO-214AC package. Rated for a continuous forward current of 1 A and a peak reverse repetitive voltage of 60 V, it offers low forward voltage drop (0.75 V max) and high surge current capability (40 A peak), making it ideal for efficient power rectification.
The device includes an over-voltage protection guard ring to enhance reliability and reduce leakage currents. Its operating temperature range from -65°C to +150°C ensures robust performance across industrial, commercial, and automotive environments.
The diode is optimized for use in applications such as low voltage, high frequency inverters, freewheeling diodes in motor control, DC/DC converter circuits, and polarity protection in power supplies. Its compact 2-pin DO-214AC (SMA) surface mount package supports easy PCB assembly and space-saving designs.
Package dimensions are precise, with length 4.6 mm, width 2.9 mm, and height 2.29 mm, facilitating integration into dense electronic assemblies. Low forward voltage drop enhances energy efficiency. Guard ring design improves over-voltage protection and device robustness.
High temperature tolerance for demanding environments. Compact surface mount packaging for modern electronics. Wide application scope including industrial electronics, power management, and automotive systems. Compliance with standard manufacturing and testing quality, although specific standards/approvals are not indicated.
This diode is manufactured in China and is supplied new in reel packaging, ideal for volume production. Explore more Vishay semiconductor components and related Schottky diodes on EnvMart for your electronic design needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay SS16-E3/5AT Schottky diode is 1 A.
This model has a peak reverse repetitive voltage rating of 60 V.
The maximum forward voltage drop for the SS16-E3/5AT is 0.75 V.
The package dimensions are 4.6 mm in length, 2.9 mm in width, and 2.29 mm in height.
The operating temperature range for the Vishay SS16-E3/5AT is from -65°C to +150°C.
The peak non-repetitive surge current rating is 40 A.
This diode supports surface mounting, suitable for compact PCB designs.
It is utilized in low voltage inverters, freewheeling diodes, DC/DC converters, and polarity protection circuits.
The peak reverse current for the SS16-E3/5AT is 200 μA.
Yes, it incorporates an over-voltage protection guard ring to enhance reliability and reduce leakage currents.
The diode configuration is single, designed for efficient power rectification.
This diode is manufactured in China.
