Molex Micro-Lock Plus Series Straight Surface PCB Header, 4 Contacts, 1.25 mm Pitch, 1 Row, Shrouded 505568-0471

Molex 505568-0471 Micro-Lock Plus Series Straight Surface PCB Header is a precision-engineered electrical connector designed for compact and high-reliability wire-to-board applications. This PCB header features a 1.25 mm pitch, single row with 4 male contacts, housed in a durable polyamide shell. Its straight orientation and surface mounting configuration facilitate seamless integration on compact printed circuit boards.

The connector incorporates brass contacts plated with tin to ensure excellent electrical conductivity and corrosion resistance. The shrouded design enhances connection integrity and reduces the risk of contact damage during assembly or operation. Rated for 1.5 A current and 50 V voltage, it is suitable for a wide range of low-voltage signal and power applications.

Operating temperature range from -40°C up to 105°C makes this connector ideal for demanding environments, including automotive steering systems, paddle shift assemblies, combination switches, and shift selectors. It is also well-suited for industrial automation equipment, consumer electronics such as gaming machines and vacuum cleaners, HVAC systems, and devices like laser printers and air conditioners.

The Micro-Lock Plus series supports color coding for easy assembly and maintenance, improving production efficiency. With a focus on reliable mechanical and electrical performance, these connectors conform to industry standards though no specific approvals are listed. Manufactured in Malaysia, this new product ensures high-quality assurance and consistent performance.

Package includes the 4-contact PCB Header with all specified features for integration into automotive, industrial, and consumer electronic devices requiring compact and dependable connector solutions.

Features a 1.25 mm pitch for high-density PCB mounting. Consists of 4 male brass contacts with tin plating for reliable electrical connection. Polyamide housing provides mechanical stability and high-temperature resistance.

Designed as a straight, surface mount wire-to-board connector for ease of assembly. Operates reliably between -40°C and 105°C for demanding environments. Supports a current rating of 1.5 A and voltage rating of 50 V. Shrouded contact design enhances electrical safety and durability.

Suitable for automotive, industrial automation, consumer electronics, and HVAC applications. Manufactured in Malaysia with new product condition ensuring reliability. Explore more Molex PCB connector components and accessories on EnvMart for your electronics manufacturing and refurbishment projects.
