Samtec EHF Series Straight Surface PCB Header, 34 Contact(s), 1.27 mm Pitch, 2 Row, Shrouded EHF-117-01-L-D-SM-LC

Samtec EHF-117-01-L-D-SM-LC is a highly reliable PCB Header featuring 34 contacts arranged in 2 straight rows with a 1.27 mm pitch. The shrouded surface mount design enhances connection security and mechanical protection, making it suitable for high-density PCB applications in industrial, electronic, and telecommunications equipment.

Constructed with a Liquid Crystal Polymer housing, this header offers exceptional mechanical strength and thermal resistance. The phosphor bronze contacts plated with gold provide excellent electrical conductivity and corrosion resistance, ensuring long-term performance.

Designed for wire-to-board connections, the header operates within a temperature range of -55°C to 125°C, accommodating a wide variety of industrial and electronic environments. The product’s male contact gender and solder termination type ensure robust and reliable solder joints on PCB assemblies.

The shrouded feature includes a polarization notch to prevent improper mating and optional caps to secure cables firmly, enhancing operational safety and reliability. This makes the header ideal for systems requiring secure and durable electronic interconnections.

The header is designed for wire-to-board connections, suitable for surface mounting. Contacts are made of phosphor bronze with gold plating for excellent conductivity and corrosion resistance. The housing is constructed from Liquid Crystal Polymer, providing durability and thermal stability.

This product operates reliably from -55°C to 125°C, suitable for demanding industrial environments. Termination type is solder, and the male contact gender supports secure connections. Shrouded design includes a polarization notch and optional caps to lock cables to the header.

Ideal for industrial electronics assembly requiring compact and robust PCB connections. Manufactured in the United States ensuring quality standards adherence.

This Samtec EHF Series PCB Header is a preferred choice for PCB assembly and electronic design engineers looking for a high-quality, durable, and thermally stable connector system for wire-to-board interconnections. Browse the Electronics & Electricals category for more advanced connectors and components at EnvMart.
