Molex 6-Way IDC Connector Female for Surface Mount, 1 Row, 250V AC, 1.2A Current, Series Picoflex 90816-0006

The Molex 90816-0006 is a 6-way IDC connector designed specifically for female surface mount applications with a single-row configuration. It supports an operating voltage of 250V AC and a current load of 1.2A, making it suitable for a wide range of electronic equipment.

This connector is part of the Picoflex series, known for high reliability and excellent space-saving features, achieving up to 50% space saving compared to traditional pitches. The pitch is 1.27mm, which supports high-density PCB design requirements.

Constructed with a brass contact material and housed in robust polyphthalamide, the connector ensures mechanical and chemical resistance essential for demanding environments. Contacts are tin-plated to enhance conductivity and corrosion resistance.

The connector operates efficiently within a temperature range from -40°C to 105°C and features a straight orientation with solder termination, facilitating secure electrical connections on printed circuit boards. The unshrouded design accommodates precise mating with compatible components.

Positive latch and polarized side posts provide increased retention and ensure correct alignment during assembly. These features improve mechanical stability and reduce the risk of connection failures owing to vibration or shock.

This IDC connector finds applications in automotive electronics, consumer devices, and industrial equipment where compact, reliable, and high-density connections are required. It supports easy integration into various electronic assemblies thanks to its design and mounting type.

Manufactured in Ireland, this Molex connector meets rigorous quality and material standards, making it a trustworthy choice for engineers and designers in multiple sectors. 6 contacts in a single row configuration provide efficient wiring solutions.

High-density 1.27mm pitch supports compact PCB layouts. Durable brass contacts and polyphthalamide housing for long service life. Wide operating temperature range from -40°C to 105°C ensures versatility. Straight orientation and solder termination for reliable connections.

Unshrouded and tin-plated contacts optimize conductivity. Positive latch and polarized posts enhance retention and alignment. Ideal for automotive and consumer electronics applications. Manufactured in Ireland adhering to quality standards.
