Molex Mini-Fit Plus Series Straight Through Hole PCB Header, 2 Contacts, 4.2 mm Pitch, 2 Row, Shrouded 46015-0203
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Copper Alloy |
| Series | Mini-Fit Plus |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The 4.2 mm pitch provides precise contact spacing for secure electrical connections.
- Constructed with durable nylon housing for enhanced mechanical strength and electrical insulation.
- Supports a current rating of 12A at 600V, suitable for medium power applications.
- The connector features a two-row design and is shrouded for enhanced safety and durability.
- Contacts are made from copper alloy with tin plating to ensure reliable conductivity and corrosion resistance.
- Operates in a temperature range from -40°C to 105°C for versatile environmental performance.
- Through-hole mounting type facilitates stable PCB assembly and solder termination.
- Male contact gender designed for mate compatibility with receptacle housings.
Product Description
Molex 46015-0203 Mini-Fit Plus Series Straight Through Hole PCB Header is a robust and reliable connector solution for electronic and power applications. Featuring a 2-contact, 2-row design with a 4.2 mm pitch, this shrouded, male-gender PCB header is engineered for high current ratings up to 12A at 600V, making it suitable for medium power wiring needs.
The connector housing is made of durable nylon, providing excellent mechanical strength and electrical insulation. The contacts consist of copper alloy plated with tin to ensure stable and corrosion-resistant conductivity over long-term use. Its operation temperature range from -40°C to 105°C enables performance in diverse industrial environments.
Designed for through-hole mounting, this header affixes securely to PCBs with solder termination, supporting wire-to-board connection systems. The shrouded housing protects the contacts to prevent accidental shorting and mechanical damage during assembly and operation.
This product is manufactured in Mexico and complies with applicable quality standards. The Mini-Fit Plus Series is compatible with Molex 5557 Series receptacle housings, providing a versatile connector solution for industrial automation, instrumentation, power supplies, and electronic manufacturing applications.
The 4.2 mm pitch offers precise and stable contact spacing. The nylon housing ensures excellent durability and insulation. Supports up to 12A current at 600V voltage rating. Shrouded design protects contacts and enhances safety.
Copper alloy contacts with tin plating provide reliable conductivity. Operates across a wide temperature range from -40°C to 105°C. Suitable for through hole solder termination mounting. Male contact gender designed for wire-to-board applications.
Manufactured to high standards in Mexico. Ideal for electronics, industrial control, and power distribution boards. Explore more Molex connectors and PCB header solutions at EnvMart for your next industrial or electronic manufacturing project.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 12A at a voltage of 600V, making it suitable for medium power applications.
The contacts in this connector are spaced at a pitch of 4.2 mm, providing precise contact spacing for secure electrical connections.
The housing is made from durable nylon, while the contacts are constructed from copper alloy with tin plating for reliable conductivity and corrosion resistance.
It operates within a temperature range from -40°C to 105°C, allowing for versatile performance in various environments.
This PCB header features 2 contacts arranged in a 2-row design.
It utilizes a through-hole mounting type, which facilitates stable PCB assembly and solder termination.
This model is shrouded, which enhances safety by protecting the contacts from accidental shorting and mechanical damage.
It supports solder termination, which is suitable for wire-to-board connection systems.
The contacts in this connector are male, designed for mate compatibility with receptacle housings.
This product is manufactured in Mexico, complying with applicable quality standards.
This model is part of the Mini-Fit Plus Series, which is compatible with Molex 5557 Series receptacle housings.
It is suitable for various applications including industrial automation, instrumentation, power supplies, and electronic manufacturing.
