Molex Mini-Fit Plus Series Straight Through Hole PCB Header, 6 Contacts, 4.2 mm Pitch, 2 Row, Shrouded 46015-0603
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Copper Alloy |
| Series | Mini-Fit Plus |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 4.2mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Designed for high current up to 12A, suitable for power applications.
- Nylon housing material for durability and resistance.
- Features a straight orientation with two rows of contacts.
- Through hole mount type ensures secure PCB connection.
- Copper alloy contacts plated with tin for excellent conductivity and corrosion resistance.
- Operates reliably between -40°C and 105°C.
- Shrouded connector system enhances protection and secure mating.
- Compatible with 5557 Series receptacle housings for versatility.
Product Description
Molex 46015-0603 Mini-Fit Plus Series PCB Header is a high-quality straight through hole connector designed for robust power transmission applications. Featuring 6 contacts arranged in 2 rows with a 4.2 mm pitch, this connector ensures reliable electrical connections in various industrial, electronic, and manufacturing settings.
The connector housing is made from durable nylon material, offering excellent mechanical strength and chemical resistance. Copper alloy contacts plated with tin provide superior conductivity and protection against corrosion. The connector is shrouded, enhancing protection and ensuring secure mating with compatible receptacles such as the Molex 5557 Series.
This PCB Header is engineered for high current carrying capacity up to 12 Amperes and rated for 600 Volts, making it suitable for power distribution and electronic device applications within stringent temperature ranges of -40°C to 105°C.
The male contact gender and through hole mount type are optimized for secure wire-to-board connections, used extensively in computing, industrial automation, instrumentation, and power supply systems.
High current capacity up to 12 Amperes. Durable nylon housing material. Two-row, 6-contact straight through hole design. Copper alloy contacts plated with tin. Wide operating temperature range from -40°C to 105°C. Shrouded design for enhanced mating security.
Voltage rating up to 600 Volts. Compatible with Molex 5557 Series receptacle housings. Manufactured in Mexico ensuring quality standards.
This connector is ideal for use in electronics manufacturing, power supply assemblies, industrial control systems, and other applications requiring reliable PCB interconnections. Explore similar Molex Mini-Fit Plus connectors and related components on EnvMart for seamless integration into your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a maximum current capacity of up to 12 Amperes, making it suitable for power applications.
The connector is rated for a voltage of up to 600 Volts, suitable for various power distribution applications.
It features a 4.2 mm pitch with 6 contacts arranged in 2 rows, designed for reliable electrical connections.
The housing is made from durable nylon, providing excellent mechanical strength and chemical resistance.
It uses copper alloy contacts that are plated with tin, ensuring excellent conductivity and corrosion resistance.
This unit operates reliably within a temperature range of -40°C to 105°C, suitable for various environments.
This model features a shrouded design, which enhances protection and ensures secure mating with compatible receptacles.
It utilizes a through hole mount type, ensuring a secure connection to the PCB.
It is compatible with Molex 5557 Series receptacle housings, providing versatility in applications.
The termination type for this connector is solder, allowing for secure connections in electronic assemblies.
This model has male contact gender, optimized for wire-to-board connections.
This connector is manufactured in Mexico, ensuring adherence to quality standards.
