RS PRO D-Sub Connector 9 Way Right Angle 2.77 mm Pitch Through Hole Female DF-9 A-DF 09 AA/Z
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | RS PRO |
| Orientation | Right Angle |
| Current | 3A |
| Model | A-DF 09 AA/Z |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | A-DF |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Pitch | 2.77mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 9 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | D-Sub |
| D-Sub Shell Size | DF-9 |
| RS PRO 9 Way Right Angle 2.77 mm Pitch Through Hole D-Sub Connector FemaleBrand | RS PRO |
Key Features
- Features right angle orientation to optimize PCB space.
- Constructed with polybutylene terephthalate housing for durability.
- Brass contacts plated with gold over nickel for reliable conductivity.
- Supports current rating of 3A and voltage of 250V.
- Operates reliably between -40°C and 105°C temperature range.
- Termination via solder connection suitable for secure PCB mounting.
- Connector shell size DF-9 accommodates 9 contacts securely.
- Designed for through hole mount type ensuring robust mechanical fixation.
Product Description
ASSMANN WSW A-DF 09 AA/Z is a high-quality D-Sub connector with 9 female contacts arranged in a right angle configuration and a 2.77 mm pitch, designed for through hole PCB mounting. The connector utilizes polybutylene terephthalate material housing which imparts strong mechanical protection and stability in electronic environments.
It supports a maximum current of 3A and voltage up to 250V. The brass contacts are plated with gold over nickel to ensure low resistance and corrosion protection, providing excellent electrical performance and durability.
This connector is suitable for operating temperatures ranging from -40°C to 105°C, making it versatile for harsh industrial conditions. The solder termination type facilitates strong and reliable electrical connections on circuit boards.
The DF-9 shell size accommodates nine contacts in a compact right angle form factor that enables efficient PCB space utilization. The through hole mounting assures secure and stable fixing on printed circuit boards, ideal for manufacturing, industrial automation, telecommunications, and electronics assembly.
Right angle orientation optimizes PCB layout. Polybutylene terephthalate housing provides durability. Gold over nickel plating enhances contact reliability. Supports 3A current and 250V voltage ratings. Operates in temperature range from -40°C to 105°C.
Solder termination assures secure electrical connections. DF-9 shell size fits 9 contacts. Through hole mount type for stable PCB fixation. Ideal for industrial and electronic manufacturing applications.
This ASSMANN WSW D-Sub connector series A-DF offers quality and performance for precise electronic and industrial circuit board connectivity needs. Browse related D-Sub Connectors and accessories at EnvMart for compatible parts and solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This D-Sub connector supports a maximum current of 3A and a voltage of up to 250V.
It operates reliably in a temperature range from -40°C to 105°C.
The connector features a pitch size of 2.77 mm.
This model has 9 female contacts arranged in a right angle configuration.
It uses a solder termination type for secure electrical connections.
The housing is constructed from polybutylene terephthalate, providing strong mechanical protection.
The shell size for this D-Sub connector is DF-9, which accommodates 9 contacts.
It features a right angle orientation, optimizing PCB space.
The contacts are made of brass and plated with gold over nickel for reliable conductivity.
This model is designed for through hole mounting, ensuring robust mechanical fixation.
The connector is manufactured in Taiwan.
This connector belongs to the A-DF series.
