Norcomp Right Angle PCB D-Sub Connector, Dual Port, 15 Contacts, Female-Male, Gold Plated, Steel Housing 189-015-613R571
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | Norcomp |
| Orientation | Right Angle |
| Model | 189-015-613R571 |
| Mount Type | PCB |
| Housing Material | Steel |
| Contact Material | Brass |
| Series | 189 |
| Mounting Hardware | 4 to 40 Insert |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.769mm |
| Contact Plating | Gold |
| Number of Contacts A | 15 |
| D-Sub Shell Size A | DA-15 |
| Contact Gender A | Female |
| D-Sub Shell Size B | DB-15 |
| Contact Gender B | Male |
Key Features
- Dual port right angle D-sub connector for PCB mounting.
- 15 contacts with female port A and male port B configuration.
- Gold plated contacts provide excellent conductivity and corrosion resistance.
- Nickel plated steel housing ensures robust shielding and durability.
- Wide operating temperature range from -55°C to 105°C.
- 4-40 insert mounting hardware enables secure retention on PCB.
- UL94V-0 thermoplastic insulator supports high temperature soldering.
- Contact material is brass for long term stability.
Product Description
Norcomp’s 189-015-613R571 is a high-performance right angle D-Sub connector engineered for PCB mount applications requiring efficient use of board real estate. This dual port connector is designed with 15 contacts, offering female connectivity on port A and male on port B, supporting standard DA-15 and DB-15 shell sizes. Its configuration allows for versatile interfacing in electronic circuits, especially where multiple connector ports must be fitted within constrained PCB space.
The connector utilizes stamped, gold plated contacts for reliable electrical performance and superior resistance to oxidation, making it suitable for both signal and data transmission. The entire assembly is housed in nickel plated steel, providing robust electromagnetic shielding and mechanical strength. Ground indents incorporated in the shell further enhance its grounding and retention capabilities, ensuring stable operation in environments affected by interference.
Mounting hardware consists of a 4-40 insert, enabling secure PCB retention via boardlocks. The insulator is constructed from UL94V-0 thermoplastic, rated for high processing temperatures up to 260°C, which supports automated solder processes common in modern manufacturing. The connector’s design supports use in a range of gender configurations, with standard density sizes available (this model supplies 15 contacts in a stacked port format).
Operating temperature ranges from -55°C to 105°C, making it appropriate for demanding industrial, laboratory, and commercial electronic environments. Contact material is brass, further improving electrical consistency and durability. Pitch between contacts is precisely 2.769 mm, ensuring compatibility with standard PCB layouts.
Application areas include industrial instrumentation, telecom equipment, computer and peripheral interfacing, and any electronic system requiring multiple durable D-sub connections in a compact footprint.
This product is part of Norcomp’s 189 Series stacked connectors, recognized for high performance, secure retention, and reliable installation. Dual port design simplifies circuit layouts and enhances signal management.
Browse the full range of D-Sub Connectors and explore Norcomp products for advanced PCB interfacing solutions at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a dual port configuration with 15 contacts, offering a female port A and a male port B setup.
The maximum operating temperature for this connector is 105°C, making it suitable for various industrial and commercial applications.
The housing is made of nickel plated steel, while the contacts are constructed from brass and are gold plated for improved conductivity and corrosion resistance.
The pitch between the contacts is 2.769 mm, ensuring compatibility with standard PCB layouts.
It includes 4-40 insert mounting hardware, which allows for secure retention on the PCB.
The minimum operating temperature is -55°C, allowing it to function in extreme conditions.
It is suitable for applications in industrial instrumentation, telecom equipment, and computer and peripheral interfacing.
The connector supports DA-15 shell size for port A and DB-15 shell size for port B.
The dual port design simplifies circuit layouts and enhances signal management by allowing multiple connections in a compact footprint.
The insulator is made from UL94V-0 thermoplastic, which supports high temperature soldering processes.
This model is part of Norcomp's 189 Series stacked connectors, known for high performance and secure retention.
The contact gender configuration is female for port A and male for port B.
