Norcomp 15 Way Right Angle 2.29 mm Pitch Through Hole D-Sub Connector with 4 to 40 Insert Male 181-015-113R531
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Norcomp |
| Orientation | Right Angle |
| Current | 3A |
| Model | 181-015-113R531 |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | 181 |
| Mounting Hardware | 4 to 40 Insert |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Shell | SPCC, Nickel Plated |
| Pitch | 2.29mm |
| Insulator | PA9T-Black - (260°C process temp) |
| Contacts | Brass, Gold Plated (Entire Contact) |
| Contact Plating | Gold Flash |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | High Density |
| Rivet | Copper Alloy, Nickel Plated |
| Board lock | SPCC, Tin Plated |
| Screw lock | Zinc Alloy, Nickel Plated |
Key Features
- Features 15 contacts with male connector gender.
- Supports a current rating of 3A and voltage up to 250V.
- Right angle orientation with through hole mount type for PCB installation.
- Constructed with brass contacts fully gold plated for reliable connectivity.
- Equipped with 4 to 40 insert mounting hardware for secure fitting.
- Contact plating includes gold flash to enhance corrosion resistance.
- Operates in a temperature range from -55°C to 105°C.
- Shell is made of nickel plated SPCC metal for EMI/RFI shielding.
Product Description
Norcomp 181-015-113R531 is a high-density 15 way right angle D-Sub connector featuring a 2.29 mm pitch and male connector gender. This connector is designed for reliable PCB mounting with through hole mount type and 4 to 40 insert mounting hardware, ensuring secure and stable installation.
The connector supports a current rating of 3A and operates at voltages up to 250V, making it suitable for various industrial and electronic applications. It performs reliably in temperature conditions ranging from -55°C minimum to a maximum of 105°C.
Constructed with brass contacts fully plated with gold flash, the connector provides excellent conductivity and corrosion resistance. The metal shell is made from nickel plated SPCC, which additionally offers EMI and RFI shielding to protect sensitive signals in demanding environments.
The insulator is manufactured from PA9T black material, capable of withstanding 260°C processing temperatures. Ancillary components such as rivets use copper alloy with nickel plating, board locks are SPCC tin-plated, and screw locks consist of zinc alloy with nickel plating, ensuring durability and mechanical stability throughout its lifespan.
This connector is ideal for use in industrial electronics, electronic component assemblies, telecommunications equipment, computing systems, and other applications requiring high-density and secure electrical junctions.
Features 15 contacts with male gender suited for right angle PCB mounting. Rated for 3A current and 250V operation voltage. Metal shell with nickel plating provides electromagnetic shielding. Gold plated brass contacts for optimal signal transmission.
Durable 4 to 40 insert mounting hardware ensures reliability. Wide operating temperature from -55°C to 105°C supports varied conditions. Materials comply with industrial requirements for insulation and durability. Explore a comprehensive range of D-Sub Connectors and power connectors on EnvMart, designed to meet professional industrial standards.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3A.
It operates at voltages up to 250V.
It features a right angle orientation with a through hole mount type for PCB installation.
The connector is constructed with brass contacts that are fully gold plated, and the shell is made of nickel plated SPCC metal.
It operates reliably in a temperature range from -55°C to 105°C.
This unit features 15 contacts with a male connector gender.
It is equipped with 4 to 40 insert mounting hardware for secure fitting.
It uses a solder termination type.
The insulator is made from PA9T black material, capable of withstanding processing temperatures of up to 260°C.
The nickel plated SPCC shell provides electromagnetic interference (EMI) and radio frequency interference (RFI) shielding.
This connector is ideal for use in industrial electronics, telecommunications equipment, and computing systems.
The country of origin for this model is Taiwan.
