| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.12mm |
| Length | 2.69mm |
| Model | BAT54T1G |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | BAT54H |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 2μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 0.4V |
| Peak Reverse Recovery Time trr | 5ns |
onsemi BAT54T1G Schottky Diode is a compact surface mount diode designed for low voltage and high frequency rectification tasks. It features a maximum continuous forward current of 200 mA and peak reverse voltage of 30 V, making it suitable for various power and signal processing applications.
The device uses the Schottky barrier principle, providing a low forward voltage drop of 0.4 V that enhances efficiency by minimizing power loss.
This diode has a peak reverse recovery time of just 5 ns, making it well suited for high-speed switching circuits and freewheeling diode roles in DC-DC converters and protection circuits.
The SOD-123 package offers a lightweight and compact form factor with dimensions of length 2.69 mm, width 1.6 mm, and height 1.12 mm, ideal for automated board assembly in dense electronic designs.
Operating reliably from -55°C to 125°C, it complies with automotive grade AEC-Q101 standards, enabling its use in automotive electronics where robustness and quality are critical. This diode supports surface mount mounting on printed circuit boards.
It offers stress protection with an epoxy moulded case for enhanced durability. The diode is Pb-free, meeting environmental standards and ensuring lead-free compliance. The device is lightweight with approximately 11.7 mg package weight, simplifying thermal management and assembly.
Typical applications include low voltage rectifiers, polarity protection diodes, and high-frequency switching. Onsemi Schottky Diodes are trusted components in industrial automation, automotive, consumer electronics, power supplies, and other high-performance semiconductor applications.
Explore more Schottky Diodes and Rectifiers to find suitable parts for your electronics and semiconductor needs at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
