onsemi 4 2-Input NOR Logic Gate 14-Pin TSSOP MC74HC02ADTR2G

onsemi MC74HC02ADTR2G is a high-performance 4 2-Input NOR Logic Gate housed in a compact 14-pin TSSOP surface-mount package, designed for applications requiring reliable and efficient logical control.

This device belongs to the 74HC family of high-speed CMOS logic ICs, providing four independent 2-input NOR gates with low power consumption and fast switching speeds. It operates on a supply voltage range of 2 to 6 volts, making it suitable for a variety of low voltage digital circuits.

The MC74HC02ADTR2G features a maximum propagation delay time of 19 nanoseconds at specified load conditions, ensuring rapid response for high-frequency logic operations. The device supports CMOS input compatibility and LSTTL output types, offering flexibility in interfacing with various logic families.

With a temperature operating range from -55°C to 125°C and conformance to the automotive AEC-Q100 standard, this logic gate is suitable for demanding environments including automotive electronics, industrial controls, and embedded systems.

The TSSOP package is designed to facilitate high-density PCB layouts with its slender 5.1 mm length and 1.05 mm height profile. The surface-mount configuration allows efficient automated assembly for volume production.

Typical use cases include digital signal processing, logic function implementation, timing and sequencing circuits in industrial automation, automotive control units, and consumer electronics where reliable logic gate performance is critical.

Offers four individual 2-input NOR gates in one device. Operates with a wide voltage range from 2 to 6 volts. High-speed CMOS technology ensures fast switching performance. Surface mount package supports efficient PCB layout and assembly.

Rated for operating temperatures from -55°C to 125°C for reliability in harsh environments. Features compatibility with CMOS input and LSTTL output types. Conforms to automotive standard AEC-Q100 indicating suitability for automotive applications.

Maximum propagation delay time is 19ns, allowing fast logic operations. Compact dimensions with length 5.1 mm and height 1.05 mm. Designed for use in industrial, automotive, and electronic manufacturing applications. Explore more electronic components and semiconductor products in the Logic Gate category at EnvMart to support your design and manufacturing needs with quality and reliability.
