Molex Mini-Latch Series Straight Through Hole Pin Header, 15 Contacts, 2.5 mm Pitch, 1 Row, Unshrouded 22-04-1151
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Latch |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- Features 15 male contacts organized in a single row for compact PCB connectivity.
- Constructed with a nylon housing and brass contacts plated with tin for durability.
- Supports current up to 3 A and voltage rating of 250 V for robust electrical performance.
- Designed with a friction locking ramp for secure mating and unshrouded for ease of soldering.
- Operates safely between -40°C and 105°C for wide environmental compatibility.
- Through hole mount type ensures stable mechanical and electrical connectivity on PCBs.
- Compatible with Mini-Latch 51191 and KK series 5051 crimp housings for versatile applications.
- Widely used in vehicles, printers, fax machines, PC monitors, and data communication centers.
Product Description
Molex 22-04-1151 Mini-Latch Series Straight Through Hole Pin Header is a high-quality wire-to-board connector featuring 15 male contacts aligned in a single row with a 2.5 mm pitch.
The product features a housing made of durable nylon and brass contacts plated with tin to ensure excellent conductivity and resistance to corrosion. It supports up to 3 A current and a voltage rating of 250 V, suitable for various electronic and industrial applications.
Designed as an unshrouded, through-hole mount type, this pin header facilitates secure solder termination while offering reliable mechanical strength. The friction locking ramp ensures a secure mating connection, preventing accidental disconnections.
Operating temperature ranges from -40°C to 105°C, allowing it to function reliably in diverse environmental conditions. The pin header is compatible with Mini-Latch 51191 and KK series 5051 2.5 mm crimp housings, providing flexibility in connector design.
Commonly employed in automotive electronics, office equipment such as fax machines and printers, PC monitors, and data communication centers, this connector system delivers a dependable interface for a wide array of wire-to-board applications.
Features 15 male contacts in a single row for compact PCB footprint. Brass contacts with tin plating ensure durability and conductivity. Nylon housing enhances mechanical resilience and insulation. Friction locking ramp mechanism secures the mating connection.
Designed for through-hole mounting to provide strong PCB attachment. Operating temperature range from -40°C to 105°C suits harsh environments. Rated for 3 A current and 250 V voltage for versatile electronic use. Compatible with Mini-Latch crimp housings for flexible connector assembly.
This Molex Mini-Latch pin header is ideal for industrial, automotive, laboratory, and commercial electronic applications requiring secure and compact wire-to-board connectors. Browse the EnvMart PCB Headers category for more options from Molex and other brands.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current of up to 3 A and a voltage rating of 250 V, suitable for various electronic applications.
The pitch size is 2.5 mm, which allows for compact PCB connectivity.
It features a nylon housing and brass contacts plated with tin for durability and excellent conductivity.
It operates safely within a temperature range of -40°C to 105°C, making it suitable for diverse environmental conditions.
This pin header has 15 male contacts organized in a single row.
It is designed for through-hole mounting, ensuring stable mechanical and electrical connectivity on PCBs.
Yes, it is compatible with Mini-Latch 51191 and KK series 5051 crimp housings for versatile applications.
It uses solder termination, which facilitates secure soldering to the PCB.
The orientation is straight, which is typical for many PCB connectors.
The contact gender is male, which is standard for pin headers.
It is commonly used in automotive electronics, office equipment like printers and fax machines, PC monitors, and data communication centers.
The country of origin for this pin header is India.
