Molex Mini-Latch Series Straight Through Hole Pin Header 12 Contacts 2.5 mm Pitch 1 Row Unshrouded 22-04-1121
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Latch |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 12 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
Key Features
- Constructed with brass contact material plated with tin for reliable conductivity.
- Features a friction locking ramp mechanism ensuring secure mating connection.
- Housing made of durable nylon, suited for operating temperatures from -40°C to 105°C.
- Designed for through-hole mounting with solder termination type and male contact gender.
- Rated for 3A current and 250V voltage, ideal for electronics and communication equipment.
- Compatible with Mini-Latch 51191 series and KK series 5051 crimp housings for versatile wiring solutions.
- Available in vertical and right-angle mounting configurations for design flexibility.
- Applicable in various industries including automotive, printers, data communication centers, and consumer electronics.
Product Description
Molex 22-04-1121 Mini-Latch Series Straight Through Hole Pin Header is engineered for reliable and secure wire-to-board connectivity with 12 contacts featuring a 2.5 mm pitch in a single row and an unshrouded form factor. It is made with brass contact material plated with tin, combined with a nylon housing that withstands operating temperatures ranging from -40°C to 105°C.
This pin header incorporates a friction locking ramp mechanism that ensures a firm and secure mating connection, enhancing the durability and safety of electrical assemblies. Suitable for through-hole solder mounting, it is designed specifically for male contacts, making it compatible with various Mini-Latch crimp housings such as the 51191 and KK series 5051.
The product supports 3A current and 250V voltage ratings, making it ideal for applications in automotive wiring, fax machines, printers, PC monitors, and data communication centers. It provides design versatility with both vertical and right-angle mounting options.
The robust nylon housing ensures high reliability during industrial and commercial use, while the unshrouded configuration allows efficient assembly and soldering processes. This header is part of the Mini-Latch 5045 and 5046 series, which are well-regarded in the electronics industry.
Constructed with brass contact material plated with tin for reliable conductivity. Friction locking ramp mechanism for secure mating. Durable nylon housing rated for -40°C to 105°C. Through-hole solder termination with male contact gender.
Rated for 3A current and 250V voltage. Compatible with Mini-Latch crimp housings for flexibility. Vertical and right-angle mounting options available. Ideal for automotive, printer, and data communication applications. Unshrouded single-row design enables easy installation.
These features make the Molex 22-04-1121 Mini-Latch Series Pin Header a dependable and flexible choice for various industrial, laboratory, manufacturing, and electronic assembly uses. Explore more electronic components and connectors in the EnvMart catalog for comprehensive PCB solutions.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Molex Mini-Latch Series pin header is rated for 250V.
This model supports a current rating of 3A.
It is designed for through-hole mounting with solder termination type.
The contacts are made of brass with tin plating, and the housing is constructed from durable nylon.
The pitch size of this pin header is 2.5 mm.
It can operate within a temperature range of -40°C to 105°C.
This pin header features 12 contacts in a single row configuration.
The contacts in this model are male.
Yes, it is compatible with Mini-Latch 51191 series and KK series 5051 crimp housings.
This model is available in both vertical and right-angle mounting configurations.
It utilizes a wire-to-board connector system.
It is applicable in various industries including automotive, printers, data communication centers, and consumer electronics.
