Lumberg Minimodul Series Straight Through Hole PCB Header, 3 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF 03

Lumberg 2,5 MSF 03 Minimodul Series Straight Through Hole PCB Header is a high-quality, shrouded male pin header with 3 contacts arranged in a single row at a 2.5 mm pitch. This connector is engineered for wire-to-board applications, providing secure and reliable connections in electronic assemblies.

The housing is made from glass filled polyamide, which ensures both mechanical robustness and excellent thermal stability, suitable for operating temperatures from -40°C to 120°C. The contacts are fabricated from brass and plated with tin, optimizing conductivity and corrosion resistance.

Designed for through-hole mounting, the straight orientation and shrouded structure prevent misalignment during assembly and protect contacts from damage. Rated for a maximum current of 5 A and voltage of 160 V, it is suitable for low to medium power electronic applications.

This Minimodul header mates with compatible crimp contact housings (3114 Series) to facilitate indirect wire-to-board connection, simplifying cable harness assembly especially in low and medium-volume production environments. Its compliance with relevant DIN EN and IEC standards attests to its quality and safety.

Provides secure and reliable electrical connection in electronic assemblies. Features a straight orientation with male contacts. Constructed with brass contacts plated with tin for durability. Glass filled polyamide housing ensures mechanical strength and thermal stability.

Operates safely between -40°C to 120°C temperature range. Designed for through-hole mounting on printed circuit boards. Rated for currents up to 5 A and voltage up to 160 V. Shrouded design provides protection and prevents misalignment during mating.

Compatible with 3114 Series crimp contact housings for wire harness assembly. Complies with DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards.

This PCB header is widely used in industrial, electronics manufacturing, telecommunications, and consumer electronics applications where reliable wire-to-board connectivity is essential. Browse more high quality PCB Headers and connectors at EnvMart to find the perfect fit for your assembly needs.
