Lumberg 14 Pole Straight M16 DIN Plug DIN EN 61076-2-106, 3A, 60V AC, IP68, Threaded Panel Mount Male 0318 14

Free Delivery in India | Lowest Global Shipping Charges

Lumberg 14 Pole Straight M16 DIN Plug DIN EN 61076-2-106, 3A, 60V AC, IP68, Threaded Panel Mount Male 0318 14

Name: Lumberg 14 Pole Straight M16 DIN Plug DIN EN 61076-2-106, 3A, 60V AC, IP68, Threaded Panel Mount Male 0318 14
Brand: LUMBERG
SKU: 127003
Price: 17.2 USD
Availability: InStock



Category DIN Connectors Brand LUMBERG Condition New

Specifications

Country of Origin	India
Voltage	60V ac
Brand	Lumberg
Orientation	Straight
Current	3A
Model	0318 14
IP Rating	IP68
Mount Type	Panel Mount
Housing Material	Die Cast Zinc
Contact Material	Brass
Series	318
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Pole Format	14
Contact Plating	Gold over Nickel
Number of Contacts	14
Contact Gender	Male
Connector Gender	Male
Mating Type	Threaded
Connector Size	M16
DIN Number	DIN EN 61076-2-106

Key Features

Meets DIN EN 61076-2-106 standard ensuring reliable connectivity.
Rated for 3A current and 60V AC voltage operation.
Offers IP68 rating for robust protection against dust and water ingress.
Constructed with die cast zinc housing for durability.
Brass contacts plated with gold over nickel for enhanced conductivity and corrosion resistance.
Operates reliably between -40°C and 85°C ambient temperatures.
Termination type is solder, providing secure electrical connection.
Designed for panel mount with a straight orientation for ease of installation.

Product Description

Lumberg 0318 14 DIN Plug is a high-quality 14 pole straight M16 connector designed for panel mount applications. It complies with the DIN EN 61076-2-106 standard and supports a current rating of 3 amperes with an operating voltage of 60V AC. The plug features a threaded mating type ensuring secure and reliable mechanical connection.

The robust die cast zinc housing offers excellent mechanical strength and durability in demanding industrial environments. Contacts are made of brass with gold over nickel plating, ensuring superior electrical conductivity and corrosion resistance. Its IP68 rating provides exceptional ingress protection against dust and water, making it suitable for harsh conditions.

Designed for stable operation within temperatures ranging from -40°C to 85°C, this DIN plug is terminated by solder contacts and intended for use with compatible connectors such as the 0322 series. Its straight orientation and panel mount male configuration allow easy installation in control engineering, automation technology, and other industrial electronic applications.

Typical applications include industrial control systems, automation, medical instrumentation, and other environments requiring durable and reliable circular connector solutions. The 0318 series supports up to 14 poles, enabling complex wiring arrangements with secure connections.

Meets DIN EN 61076-2-106 standard for DIN plugs. Current rating of 3A and voltage rating of 60V AC. IP68 protection rated for dust-tight and water immersion resistance. Die cast zinc housing provides mechanical robustness.

Brass contact material plated with gold over nickel for enhanced electrical performance. Operates in extreme temperature ranges from -40°C to 85°C. Solder termination for reliable contact connections. Suitable for panel mount installation with threaded connection.

Compatible with 0322 connectors for mating. Explore additional Lumberg DIN connector products in the EnvMart catalog for industrial quality electronic components and connectors.
