Taiwan Semiconductor 1-Element Uni-Directional TVS Diode 400 W Power, 2-Pin DO-214 SMAJ13A R3

Free Delivery in India | Lowest Global Shipping Charges

Taiwan Semiconductor 1-Element Uni-Directional TVS Diode 400 W Power, 2-Pin DO-214 SMAJ13A R3

Name: Taiwan Semiconductor 1-Element Uni-Directional TVS Diode 400 W Power, 2-Pin DO-214 SMAJ13A R3
Brand: Taiwan Semiconductor
SKU: 211921



Category Semiconductors Brand Taiwan Semiconductor Condition New

Specifications

Country of Origin	India
Brand	Taiwan Semiconductor
Height	2.3mm
Length	4.6mm
Model	SMAJ13A R3
Width	2.83mm
Mount Type	Surface
Series	SMAJ
Maximum Operating Temperature	150°C
Package Type	DO-214
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Clamping Voltage VC	21.5V
Diode Configuration	Single
Direction Type	Uni-Directional
Minimum Breakdown Voltage Vbr	14.4V
Maximum Reverse Stand-off Voltage Vwm	13V
Peak Pulse Power Dissipation Pppm	400W
Test Current It	1mA
Maximum Peak Pulse Current Ippm	18.6A
Maximum Reverse Leakage Current	5μA

Key Features

Single diode configuration specialized for uni-directional transient voltage suppression.
Operates at a minimum breakdown voltage of 14.4 V for robust protection.
Maximum reverse standoff voltage rated at 13 V to prevent circuit damage.
Clamping voltage of 21.5 V ensures fast voltage spike absorption.
Wide operating temperature range from -55°C to 150°C suitable for various environments.
Compact DO-214 package featuring 2 pins for easy surface mounting.
Peak pulse power dissipation of 400 W and maximum peak pulse current of 18.6 A for effective transient suppression.
Reliable ESD protection and stable operation with test current of 1 mA.

Product Description

Taiwan Semiconductor SMAJ13A R3 1-Element Uni-Directional TVS Diode provides reliable transient voltage suppression with a peak pulse power dissipation of 400 W. It is designed for surface mount applications in industrial and electronic equipment to protect sensitive circuits from voltage spikes and electrostatic discharges.

This diode features a single uni-directional element with a minimum breakdown voltage of 14.4 V and a maximum reverse stand-off voltage of 13 V, which effectively clamps voltage transients at 21.5 V to safeguard components.

The SMAJ13A R3 is housed in a compact DO-214 2-pin package with dimensions 4.6 mm length, 2.83 mm width, and 2.3 mm height, allowing for efficient PCB placement and integration.

Operating temperature ranges from -55°C to 150°C, making it suitable for a wide variety of industrial, manufacturing, automotive, and electronic applications requiring robust transient voltage protection.

The device offers a maximum peak pulse current of 18.6 A and includes electrostatic discharge (ESD) protections, ensuring stability and durability in high-stress electrical environments.

Single diode uni-directional transient voltage suppression. Peak pulse power dissipation of 400 W for high energy transients. Compact and easy-to-mount DO-214 surface mount package. Wide temperature operation from -55°C to 150°C.

Protects electronic circuits in industrial, automotive and commercial equipment.

This Taiwan Semiconductor product embodies robust design and reliability, optimized for protecting electronic circuits from voltage surges. It is suitable for engineers and designers looking to enhance circuit reliability in sensitive electronic systems.
