Molex KK 396 Series Straight Through Hole Pin Header 9 Contacts 3.96 mm Pitch 1 Row Unshrouded 26-48-1095
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 4.37mm |
Key Features
- Features a straight orientation and unshrouded design for easy soldering and mounting.
- Constructed with brass contacts plated in tin and housed in durable polyester material.
- Supports up to 7 amps current and operates at a voltage of 250V.
- Suitable for through-hole mounting providing secure mechanical and electrical connection.
- Operating temperature range from -40°C to 80°C ensures stable performance in various environments.
- Tail pin length measures 4.37 mm enabling robust solder joint formation.
- Compatible with various Molex housing and connector series for versatile applications.
Product Description
Molex 26-48-1095 KK 396 Series Straight Through Hole Pin Header is a high-quality electronic connector designed for industrial and electronics applications. It features a single row of 9 male contacts spaced at a pitch of 3.96 mm, making it ideal for wire-to-board connections requiring robust performance.
The connectors use brass contacts with tin plating housed within a durable polyester material, ensuring longevity and resistance to wear. The straight orientation and unshrouded format facilitate easy mounting and soldering during PCB assembly. This header is designed for through-hole mounting, providing excellent mechanical stability.
Electrical specifications include a current rating of 7A and voltage handling capability of 250V, while supporting operating temperatures from -40°C to 80°C. The tail pin length is 4.37 mm, which ensures reliable solder joints and connectivity.
The KK 396 series pin header is compatible with a broad range of Molex housings and connectors such as the 3069, 2139, 6442, 41695 series housings, 7674, 7675 series IDT connectors, and PCB connectors from series 41815, 2145, and 3215. This versatility allows integration into various electronic devices and systems.
Used extensively in industrial manufacturing, laboratory instrumentation, electronics assembly, and commercial applications, this pin header provides dependable connectivity in demanding environments. Its robust build and standardized dimensions make it a preferred choice for engineers and technicians.
Features a straight orientation and unshrouded design for easy soldering and mounting. Constructed with brass contacts plated in tin and housed in durable polyester material. Supports up to 7 amps current and operates at a voltage of 250V.
Suitable for through-hole mounting providing secure mechanical and electrical connection. Operating temperature range from -40°C to 80°C ensures stable performance in various environments. Tail pin length measures 4.37 mm enabling robust solder joint formation.
Compatible with various Molex housing and connector series for versatile applications. Explore a comprehensive range of PCB Headers and connectors from Molex on EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of up to 7 amps.
This pin header operates at a voltage of 250V.
The contacts are spaced at a pitch of 3.96 mm.
The tail pin length measures 4.37 mm.
It operates within a temperature range from -40°C to 80°C.
It is constructed with brass contacts plated in tin and housed in durable polyester material.
Yes, it is designed for through-hole mounting, providing a secure mechanical and electrical connection.
This model features 9 male contacts.
It uses solder termination for secure connections.
It is compatible with various Molex housing series, including 3069, 2139, and 6442.
It features a straight orientation for easy soldering and mounting.
It is used extensively in industrial manufacturing, laboratory instrumentation, and electronics assembly.
