Molex 1 mm Pitch 9 Way Right Angle Male FPC Connector, Surface Mount, Gold Plated, 500mA, 50V AC 200528-0090
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50, 50V ac |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | 200528 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Easy-On FFC/FPC Connector |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 9 |
| Contact Gender | Male |
| Connector Gender | Male |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- The right angle design enables easy installation in compact spaces.
- Gold plating provides excellent conductivity and corrosion resistance.
- Constructed with phosphor bronze contacts and liquid crystal polymer housing for durability.
- Features zero insertion force (ZIF) for effortless cable insertion and removal.
- The connector supports high operating temperatures up to 105°C for harsh environments.
- Locking mechanism ensures secure and reliable connections.
- Compatible with a wide range of electronic devices requiring 1mm pitch connectors.
Product Description
Molex 200528-0090 is a high-quality, 1 mm pitch, 9 way right angle male FPC connector designed for reliable surface mount PCB assembly. Rated for 500mA current and 50V AC voltage, this connector supports demanding electronic environments with its rugged liquid crystal polymer housing and gold plated phosphor bronze contacts.
The right angle orientation facilitates installation in tight spaces where board real estate is limited. Its zero insertion force (ZIF) design reduces mechanical stress on contacts during assembly and maintenance. The locking mechanism assures stable connections even under vibration or thermal cycling.
Its robust construction allows a maximum operating temperature of 105°C, making it suitable for automotive infotainment systems, display audio equipment, personal navigation devices, and consumer flat panel TVs. The 1 mm pitch ensures compatibility with various FPC cables and other electronic components.
With precise solder termination on the bottom contact position, this connector enables efficient PCB surface mounting with secure electrical performance. The gold over nickel plating ensures long-lasting conductivity and corrosion resistance essential for high-reliability applications.
Applications range across automotive navigation, consumer electronics, and industrial devices requiring compact, durable FPC Connectors. Molex's easy-on series is designed to facilitate fast, dependable assembly and serviceability.
The right angle design enables easy installation in compact spaces. Gold plating provides excellent conductivity and corrosion resistance. Constructed with phosphor bronze contacts and liquid crystal polymer housing for durability.
Features zero insertion force (ZIF) for effortless cable insertion and removal. The connector supports high operating temperatures up to 105°C for harsh environments. Locking mechanism ensures secure and reliable connections.
Compatible with a wide range of electronic devices requiring 1mm pitch connectors. Explore the complete range of electronic connectors and components to optimize your PCB design and assembly at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature of this connector is 105°C, making it suitable for harsh environments.
This model is rated for a current of 500mA.
It can handle a voltage of 50V AC.
The housing is made of liquid crystal polymer, and the contacts are constructed from phosphor bronze with gold over nickel plating.
The pitch size of this connector is 1mm.
This connector has 9 contacts.
It uses a solder termination type for secure connection to PCBs.
The connector features a right angle orientation, facilitating installation in compact spaces.
Yes, it has a locking mechanism that ensures secure and reliable connections even under vibration or thermal cycling.
This connector features a zero insertion force (ZIF) design for effortless cable insertion and removal.
The minimum operating temperature is -40°C.
The connector is manufactured in Japan.
