Molex KK 396 Series Straight Through Hole Pin Header, 3 Contact(s), 3.96 mm Pitch, 1 Row, Unshrouded 26-48-1035
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 7A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | KK 396 |
| Termination Type | Solder |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3.96mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 4.37mm |
Key Features
- Features a straight orientation male pin header design.
- Constructed with polyester housing and brass contacts plated with tin.
- Supports a current rating of 7A and voltage up to 250V.
- Operates reliably within a temperature range of -40°C to 80°C.
- Tail pin length measures 4.37 mm for secure solder termination.
- Compatible with multiple housing series for versatile applications.
- Designed for wire-to-board connector system with through hole mount type.
- Unshrouded design allows easy mating and inspection of contacts.
Product Description
Molex 26-48-1035 KK 396 Series Straight Through Hole Pin Header is a high-quality connector designed for wire-to-board applications. It features a 3-contact setup with a 3.96 mm pitch and single-row configuration, suitable for printed circuit boards requiring reliable electrical connections.
This unshrouded male pin header is constructed with a durable polyester housing and brass contacts plated with tin, ensuring excellent conductivity and corrosion resistance. The straight orientation facilitates easy installation and mating with compatible housings.
Operating within a wide temperature range from -40°C to 80°C, this header supports currents up to 7 amperes and voltages up to 250 volts, making it suitable for diverse industrial and electronic applications.
The tail pins, with a length of 4.37 mm, are optimized for solder termination, ensuring a secure and stable connection. The MK 396 series headers mate with various housing and connector series, enhancing versatility in electronic designs.
Features a straight orientation male pin header design. Constructed with polyester housing and brass contacts plated with tin. Supports a current rating of 7A and voltage up to 250V. Operates reliably within a temperature range of -40°C to 80°C.
Tail pin length measures 4.37 mm for secure solder termination. Compatible with multiple housing series for versatile applications. Designed for wire-to-board connector system with through hole mount type. Unshrouded design allows easy mating and inspection of contacts.
This product is commonly used in industrial electronics, manufacturing equipment, and other applications requiring precise and reliable PCB connections. It is ideal for custom electrical assemblies, testing setups, and high-performance electronic devices.
Choose Molex KK 396 Series Straight Through Hole Pin Header 26-48-1035 for trusted performance and durability in your electronics projects. Explore more PCB connector options and technical components from EnvMart to enhance your electronic designs with quality and innovation.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 7A and a voltage rating of up to 250V.
It features a pitch of 3.96 mm and has 3 contacts arranged in a single row.
The housing is made of polyester, while the contacts are brass plated with tin for improved conductivity and corrosion resistance.
The tail pin length measures 4.37 mm, optimized for solder termination.
It operates reliably within a temperature range of -40°C to 80°C.
This unit is designed for through hole mounting, suitable for printed circuit boards.
This pin header is unshrouded, allowing for easy mating and inspection of contacts.
It is designed for a wire-to-board connector system.
Yes, it is compatible with multiple housing series, enhancing its versatility in applications.
The orientation of this model is straight, facilitating easy installation.
The country of origin for this pin header is India.
The contacts in this pin header are male.
