Molex KK 254 Series Right Angle Through Hole Pin Header 10 Contacts 2.54 mm Pitch 1 Row Unshrouded 22-05-3101

Molex 22-05-3101 KK 254 Series Right Angle Through Hole Pin Header is a high-quality electronic connector designed for robust wire-to-board applications. This component features 10 male contacts arranged in one row with a 2.54 mm pitch suited for precise signal transmission on printed circuit boards.

The housing is manufactured from white nylon UL 94V-0 material which provides excellent mechanical strength and flame retardancy. The right angle orientation of the pin header facilitates compact PCB assembly layouts and versatile interconnections.

Each brass contact is tin plated to enhance corrosion resistance and solderability, ensuring reliable long-term performance. The connector supports currents up to 4 amperes at voltages up to 250 volts, making it appropriate for a variety of low power industrial electronic solutions.

It operates reliably over a temperature range of -40°C to 105°C, capable of withstanding rigorous industrial and environmental conditions. Termination is through-hole solder, with tail pins measuring 3.58 mm in length to provide secure and stable mounting.

This unshrouded header design allows for end-to-end stacking and mates compatibly with Molex 2695 Series housings that incorporate friction lock features. These characteristics make it an excellent choice for industrial control systems, automation equipment, and electronic manufacturing assemblies demanding quality connector solutions.

It is widely used in electronics components assembly within industrial, laboratory, and manufacturing sectors. The connector features a right angle orientation for versatile PCB layout. Constructed with nylon housing material rated UL 94V-0 for flame resistance.

Brass contacts are tin-plated to ensure corrosion resistance and solderability. Rated for 4A current and 250V voltage, suitable for low power electronic assemblies. Termination via soldering with a male contact gender and 3.58 mm tail pin length.

Operating temperature range from -40°C to 105°C supports varied industrial environments. This unshrouded pin header allows end-to-end stacking compatibility with Molex 2695 Series housings. Ideal for use in industrial electronics, control systems, and PCB interconnections.
