Molex Milli-Grid Series Straight Surface PCB Header 8 Contacts 2 mm Pitch 2 Row Shrouded 87832-5322

Molex 87832-5322 is a Milli-Grid Series straight surface mount PCB header featuring 8 male contacts arranged in 2 rows with a 2 mm pitch. This shrouded connector system is designed for wire-to-board applications, offering reliable high-density interconnections suitable for industrial, electronics manufacturing, and power connector environments.

The housing is constructed from durable nylon, providing excellent insulation and mechanical support. Contact terminals are made from phosphor bronze, plated with 0.38μm of gold ensuring optimal conductivity and resistance to corrosion. The connector operates effectively within a temperature range of -55°C to 105°C and supports a current rating of 2A and voltage up to 125V.

This PCB header utilizes solder termination, facilitating secure and permanent mounting on circuit boards. It is compatible with Molex 51110 Series receptacles, enabling modular and flexible design configurations. The shrouded male contacts prevent misalignment and provide protection during assembly processes.

The Milli-Grid connector system is based on a 2 x 2 mm grid pattern, offering design flexibility for board-to-board and cable-to-board connections in electronics, power systems, and industrial machines. Its compact footprint and high reliability make it ideal for demanding applications such as automation, manufacturing, and instrumentation.

The connector supports a current rating of 2 amperes for reliable electrical performance. Constructed with a nylon housing to ensure insulation and mechanical robustness. Contact material is phosphor bronze plated with gold for excellent conductivity and corrosion resistance.

Operating temperature range from -55°C to 105°C allows use in various industrial environments. Designed for solder termination and mates with Molex 51110 Series receptacles for compatibility. Provides a compact 2 mm row pitch making it ideal for high-density PCB connections.

Shrouded male contacts enhance safety and prevent misalignment during assembly. Rated voltage is 125 volts, making it suitable for low voltage electronics.

This product is an essential component for electronics manufacturing, instrumentation, industrial automation, and power distribution systems. Molex connectors are renowned for quality and durability ensuring long service life in challenging conditions.
