Molex C-Grid III Series Right Angle Through Hole PCB Header, 6 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 90136-2206
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Right angle, single row PCB header designed for through-hole mounting.
- Features 6 male contacts with gold-plated brass material for reliable conductivity.
- Housing constructed from durable polyester and is shrouded for secure connection.
- Supports a current rating of 3A and a voltage rating of 350V.
- Operates within a temperature range from -55°C to 125°C for diverse applications.
- Provides solder termination with a tail pin length of 2.9 mm and mating pin length of 6.75 mm.
- Connector system is wire-to-board, optimizing PCB assembly integration.
- Suitable standard pitch of 2.54 mm supports compatibility with various electronic designs.
Product Description
Molex 90136-2206 is a high-quality Right Angle Through Hole PCB Header from the C-Grid III Series, designed for effective wire-to-board connections in electronic components and assemblies.
With a pitch of 2.54 mm and consisting of 6 gold-plated male brass contacts arranged in a single row, it ensures excellent electrical conductivity and low contact resistance. The polyester housing is robust and shrouded, providing protection and secure mating with compatible locking housings.
Rated for 3A current and 350V voltage, this PCB header maintains reliable performance over a wide operating temperature range of -55°C to 125°C, suitable for demanding industrial and commercial electronics environments.
The right angle orientation facilitates space-efficient PCB layouts and easy integration in compact assemblies. Solder termination with a tail pin length of 2.9 mm aids secure mounting, while the mating pin length of 6.75 mm ensures proper contact insertion depth.
This component is ideal for industrial, manufacturing, and commercial electronics applications requiring dependable wire-to-board interconnections with durable construction and precise engineering standards.
Right angle, single row PCB Header designed for through-hole mounting. Features 6 male contacts with gold-plated brass material for reliable conductivity. Housing constructed from durable polyester and is shrouded for secure connection.
Supports a current rating of 3A and a voltage rating of 350V. Operates within a temperature range from -55°C to 125°C for diverse applications. Provides solder termination with a tail pin length of 2.9 mm and mating pin length of 6.75 mm.
Connector system is wire-to-board, optimizing PCB assembly integration. Suitable standard pitch of 2.54 mm supports compatibility with various electronic designs. Explore more PCB connector solutions and designs at EnvMart to find the perfect match for your electronic projects and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 3A.
It has a voltage rating of 350V.
The pitch of this model is 2.54 mm, which supports compatibility with various electronic designs.
The housing is made from durable polyester, and the contacts are gold-plated brass for reliable conductivity.
It operates within a temperature range from -55°C to 125°C.
This header features 6 male contacts arranged in a single row.
It provides solder termination with a tail pin length of 2.9 mm.
The mating pin length is 6.75 mm, ensuring proper contact insertion depth.
This unit uses a wire-to-board connector system, optimizing PCB assembly integration.
It is shrouded, providing protection and secure mating with compatible locking housings.
The orientation of this model is right angle, facilitating space-efficient PCB layouts.
The country of origin for this PCB header is India.
