Molex C-Grid III Series Right Angle Through Hole PCB Header, 4 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 90136-2204

Molex 90136-2204 C-Grid III Series Right Angle Through Hole PCB Header features 4 male contacts arranged in a single row with a 2.54 mm pitch, designed for secure wire-to-board connections in electronic assemblies. The shrouded header ensures locking housings provide stable and durable connections, reducing the risk of connector disengagement during operation.

The contact material is brass with gold plating to provide excellent electrical conductivity and corrosion resistance, supporting a continuous current of 3 amperes and a voltage rating of 350 volts. This product is intended for through hole mounting on printed circuit boards, with a tail pin length of 2.9 mm and mating pin length of 6.75 mm to accommodate standard PCB designs.

Constructed with a polyester housing, this PCB header offers mechanical strength and electrical insulation while operating reliably in temperatures ranging from -55°C to 125°C, suitable for demanding industrial environments. Its right angle orientation allows for efficient cable routing and compact board layouts in electronics manufacturing and prototyping.

This connector is essential for applications in general electronics assembly, industrial controls, consumer electronics, telecommunications equipment, and any scenario requiring durable, secure PCB connections. The Molex C-Grid III series is a trusted solution that integrates quality materials and precise engineering to ensure long-lasting performance in critical electrical applications.

The header is right angle type with a shrouded design for higher connection security. 4 contact pins spaced at 2.54 mm pitch for standard PCB compatibility. Brass contacts plated with gold for enhanced conductivity. Rated for 3A current and 350V voltage with wide temperature operating range.

Single row configuration suited to compact PCB designs. Housing material is polyester for durability and electrical insulation. Through hole mount type with specified pin lengths for reliable soldering.

Find trusted Molex PCB Headers and connectors in the Electronics & Electricals category at EnvMart. Enhance your circuit board assembly and electronics projects with quality connectors designed for precision and reliability.
