Molex C-Grid III Series Right Angle Through Hole PCB Header 5 Contact 2.54mm Pitch 1 Row Shrouded 90136-2205

Molex 90136-2205 is a high-quality C-Grid III Series right angle through hole PCB header featuring 5 contacts arranged in a single row with a 2.54 mm pitch. Designed for wire-to-board connector systems, this shrouded header offers secure and reliable electrical connections suitable for industrial and electronic applications.

The housing is made from durable polyester, ensuring excellent insulation properties and mechanical stability. Contacts are constructed of brass and plated with gold to provide superior conductivity and resistance to corrosion over extended use.

This PCB header operates reliably under a wide temperature range from -55°C to 125°C and handles voltage up to 350V with a current rating of 3A, making it suitable for demanding electronic assemblies. It utilizes a through hole mount type with solder tail pins 2.9 mm in length, facilitating strong mechanical and electrical connections during PCB assembly.

Its right angle orientation with locking features supports compact PCB layouts and enhances connector stability. The shrouded design provides protection for the contacts and reduces the risk of accidental shorts or damage, essential in industrial, manufacturing, and electronics prototyping environments.

The 6.75 mm mating pin length ensures adequate engagement depth with corresponding connectors, ensuring signal integrity and mechanical robustness in usage. This product is new, conforms to no explicit approvals or certifications, and is designed for applications requiring reliable wire-to-board connectivity.

Right angle orientation for locking with housings provides stability. Gold-plated brass contacts deliver excellent electrical performance. Polyester housing ensures insulation and durability. Operates in temperatures from -55°C to 125°C for versatile use.

Rated for voltage up to 350V and current up to 3A. Solder termination with 2.9 mm tail pin length for effective soldering. Shrouded single row, 5 contact header suited for compact layouts. Through hole mounting ensures strong PCB attachment.

Ideal for industrial, electronic component assembly, and prototyping. Explore a wide range of PCB Headers and connectors in the Electronics & Electricals category on EnvMart to find the perfect fit for your project or industrial application.
