Molex C-Grid III Series Straight Through Hole Pin Header 5 Contacts 2.54 mm Pitch 1 Row Unshrouded 90120-0765

Molex 90120-0765 C-Grid III Series Straight Through Hole Pin Header is a high-quality wire-to-board connector component featuring 5 male contacts arranged in a single row with 2.54 mm pitch spacing. This unshrouded pin header utilizes brass contacts plated in gold to provide excellent electrical conductivity and corrosion resistance. The pins terminate with a solder tail length of 2.9 mm suitable for through-hole mounting onto printed circuit boards.

The C-Grid III series is designed to meet modern industry requirements offering a breakaway design that enables custom length configurations for enhanced design flexibility. Operating at a current rating of 3 amps and voltage rating of up to 350 volts, the header supports reliable electrical connections in a wide variety of environments with an operating temperature range from -55°C to 125°C.

The straight orientation and unshrouded construction facilitate mating with C-Grid III series PCB sockets and crimp housings commonly used for both board-to-board and wire-to-board applications. The high pin retention force and mechanical stability once soldered ensure a secure connection that withstands vibrations and mechanical stresses in industrial, medical, telecommunications, consumer, and automotive safety electronics applications.

Applications include use in desktop PCs, servers, monitors, medical equipment, white goods, exchange stations, industrial automation equipment, and automotive safety systems. The connector's robust design and compliance ensure it integrates seamlessly into demanding electronic component assemblies.

Comprises 5 male contacts arranged in a single row. Pitch spacing between pins is 2.54 millimeters ensuring industry standard compatibility. Through hole mount type with solder tail pin length of 2.9 mm for robust PCB installation.

Contact material is brass with gold plating for improved conductivity and corrosion resistance. Rated for current up to 3 amps with voltage rating of 350 volts. Operates reliably from -55°C up to 125°C for broad environmental tolerance.

Unshrouded straight orientation allows easy mating with C-Grid III sockets and crimp housings. Breakaway design allows customization of connector length for flexible PCB layouts. High mechanical stability and pin retention force ensure secure mating and durability post-soldering.

Suitable for industrial, computer, medical, telecommunications, and automotive safety systems applications. For more products in the Molex C-Grid III series and related PCB connectors, explore the selection at EnvMart Electronics & Electricals category.
