Molex C-Grid III Series Right Angle Through Hole PCB Header, 16 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded 90130-3116

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Right Angle Through Hole PCB Header, 16 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded 90130-3116

Name: Molex C-Grid III Series Right Angle Through Hole PCB Header, 16 Contact(s), 2.54 mm Pitch, 2 Row, Shrouded 90130-3116
Brand: Molex
SKU: 206731
Price: 2.37 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Right Angle
Current	3A
Mount Type	Through Hole
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	16
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm

Key Features

Right angle header suitable for locking housings.
Shrouded design ensures secure connections.
Contact material is brass with tin plating for corrosion resistance.
Mount type is through hole for strong PCB attachment.
Operating voltage rated at 350V.
Designed for current of up to 3A.
Tail pin length measures 2.9 mm for reliable soldering.
Minimum and maximum operating temperature ranges from -55°C to 125°C.

Product Description

Molex 90130-3116 is a right angle through hole PCB header from the C-Grid III series featuring 16 contacts arranged in 2 rows with a 2.54 mm pitch. This shrouded header is designed for wire-to-board connector systems, ensuring secure and reliable electrical connections in industrial and electronic assemblies.

The header is constructed with brass contact material coated with tin plating to enhance durability and resistance against corrosion. It is suitable for applications requiring up to 3 amperes current and operating voltages up to 350 volts. The tail pin length of 2.9 mm allows for dependable solder termination through holes on printed circuit boards.

Operating reliably across a temperature range from -55°C to 125°C, this component is ideal for use in electronic components, industrial equipment, and control systems where robust PCB connection is essential. The right angle and shrouded design facilitates locking housings, improving mechanical stability and preventing accidental disconnections during operation.

This PCB header fits seamlessly into through hole mount configurations, ensuring high quality and durable installation on printed circuit boards. It supports a wire-to-board connector system commonly applied in power supply connections, signal transmissions, and electronic control modules.

Right angle header suitable for locking housings. Shrouded design ensures secure connections. Contact material is brass with tin plating for corrosion resistance. Mount type is through hole for strong PCB attachment. Operating voltage rated at 350V.

Designed for current of up to 3A. Tail pin length measures 2.9 mm for reliable soldering. Minimum and maximum operating temperature ranges from -55°C to 125°C. Connector system supports wire-to-board connections. Termination type is solder for firm electrical contact.

This high quality PCB header is widely used in electronics manufacturing, power distribution units, industrial control systems, and telecommunications equipment. For more options, explore the PCB Headers category at EnvMart.
