Molex C-Grid III Series Straight Through Hole Pin Header 26 Contact 2.54 mm Pitch 2 Row Unshrouded 90131-0133
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Features a breakaway design allowing custom length adjustments.
- Unshrouded male pins ensure robust mechanical stability once soldered.
- Constructed with brass contacts plated in tin for reliable conductivity.
- Rated for 3 A current and supports up to 350 V operating voltage.
- Suitable for through-hole mounting in industrial and electronic applications.
- Operates reliably in temperatures ranging from -55°C to 125°C.
- Provides secure, high retention force mating with compatible C-Grid III sockets.
- Ideal for wire-to-board and board-to-board interconnections in diverse industries.
Product Description
Molex 90131-0133 C-Grid III Series Straight Through Hole Pin Header offers a high-quality solution for wire-to-board connections with 26 male contacts arranged in 2 rows at a 2.54 mm pitch. It supports a current carrying capacity of 3 A and operates efficiently at voltages up to 350 V. The connectors are built with brass contacts plated in tin, housed in durable polyester material, ensuring long-term reliability and secure soldering.
This series features a breakaway design permitting users to cut the header to desired lengths, enhancing design flexibility. The unshrouded pins provide excellent retention force for mating components and ensure high mechanical stability once soldered to a PCB. Designed for through-hole mounting, this pin header suits a variety of industrial, computing, medical, consumer electronics, telecommunications, and transportation applications.
Operating temperature ranges from -55°C to 125°C, making it suitable for harsh environments and demanding conditions. The C-Grid III pin headers are compatible with C-Grid III sockets and crimp housings, enabling both board-to-board and wire-to-board interfacing. Its secure connection properties support use cases including desktop PCs, servers, medical equipment, white goods, industrial machinery, and automotive safety systems.
Breakaway header design for customizable pin count and length. Brass contacts with tin plating for effective electrical conductivity. Polyester housing resistant to environmental conditions. Through-hole mount type for permanent, robust PCB attachment.
High retention and mechanical stability ensuring durable connections. Wide operating temperature range between -55°C and 125°C for versatile use. Unshrouded male contacts optimize mating with compatible sockets. Supports 3 A current and 350 V voltage rating in demanding environments.
This Molex C-Grid III Series pin header is engineered to meet the latest industrial standards, making it an ideal choice for engineers and designers needing reliable, flexible PCB connector solutions. Explore more PCB connectors and headers on EnvMart for your precise manufacturing and assembly requirements.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3 A and can operate at voltages up to 350 V.
It features a pitch of 2.54 mm and has 26 male contacts arranged in 2 rows.
The contacts are made of brass and are plated in tin, while the housing is constructed from durable polyester.
It operates reliably in temperatures ranging from -55°C to 125°C.
This pin header is designed for through-hole mounting, ensuring a permanent and robust attachment to the PCB.
Yes, it features a breakaway design that allows users to cut the header to the desired lengths for customization.
It is suitable for various applications including industrial, computing, medical, consumer electronics, telecommunications, and transportation.
The termination type for this model is solder, allowing for secure connections to the PCB.
The contacts are male and oriented straight, providing a straightforward connection method.
The tail pin length is 2.9 mm, while the mating pin length is 6.75 mm.
Yes, it is compatible with C-Grid III sockets and crimp housings, enabling both board-to-board and wire-to-board interfacing.
