Molex C-Grid III Series Straight Through Hole PCB Header 34 Contacts 2.54 mm Pitch 2 Row Shrouded 90130-1134
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 34 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Compatible with 2.54 mm pitch PCB applications for precise connectivity.
- Constructed with brass contacts plated in tin for reliable electrical performance.
- Polyester housing ensures durable and stable insulation.
- Supports current rating of 3A and voltage rating of 350V for varied electronic uses.
- Designed with straight orientation and shrouded for secure mating and protection.
- Suitable for through-hole mounting with solder termination type for PCB assembly.
- Operating temperature range from -55°C to 125°C suits harsh environments.
- Tail pin length of 2.9 mm and mating pin length of 6.75 mm facilitate connectivity.
Product Description
Molex 90130-1134 C-Grid III Series Straight Through Hole PCB Header is engineered for robust electronic connections requiring a wire-to-board interface. This component features 34 male contacts arranged in 2 rows with a precise 2.54 mm pitch, optimizing PCB space usage while maintaining reliable connectivity.
Manufactured from durable polyester housing to provide electrical insulation and mechanical strength, this header includes brass contacts plated with tin for corrosion resistance and excellent conductivity. It is designed for through-hole mounting and solder termination, facilitating secure attachment to printed circuit boards.
Rated for 3A current and 350V voltage, this PCB header performs reliably within an operating temperature range of -55°C to 125°C, making it suitable for various industrial and commercial electronic applications. The product's shrouded design protects contacts and aids in secure locking with compatible housings.
With tail pin and mating pin lengths of 2.9 mm and 6.75 mm respectively, the header ensures stable insertion and connection. This product is ideal for use in manufacturing, testing, and repair of electronic devices requiring standard pitch PCB Headers.
Compatible with 2.54 mm pitch PCB applications for precise connectivity. Constructed with brass contacts plated in tin for reliable electrical performance. Polyester housing ensures durable and stable insulation. Supports current rating of 3A and voltage rating of 350V for varied electronic uses.
Designed with straight orientation and shrouded for secure mating and protection. Suitable for through-hole mounting with solder termination type for PCB assembly. Operating temperature range from -55°C to 125°C suits harsh environments.
Tail pin length of 2.9 mm and mating pin length of 6.75 mm facilitate connectivity. Explore the extensive range of PCB connectors and headers available to improve your electronic projects and assemblies efficiently.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a current rating of 3A and a voltage rating of 350V, making it suitable for various electronic applications.
The contacts in this model have a pitch of 2.54 mm, which is compatible with standard PCB applications.
It features 34 male contacts arranged in 2 rows, optimizing space on the PCB while ensuring reliable connectivity.
The header is constructed with brass contacts plated in tin for corrosion resistance, and the housing is made of durable polyester for insulation.
It operates within a temperature range of -55°C to 125°C, making it suitable for harsh environments.
This model is designed for through-hole mounting with a solder termination type for secure attachment to printed circuit boards.
The tail pin length is 2.9 mm, which facilitates stable insertion and connection.
The mating pin length is 6.75 mm, ensuring a secure connection with compatible housings.
This model has a straight orientation, designed for easy and secure mating.
The header is shrouded, which provides protection for the contacts and aids in secure locking with compatible housings.
It utilizes a wire-to-board connector system, suitable for robust electronic connections.
The country of origin for this PCB header is India.
