Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header 10 Contact 3 mm Pitch 2 Row Shrouded 43045-1009

Free Delivery in India | Lowest Global Shipping Charges

Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header 10 Contact 3 mm Pitch 2 Row Shrouded 43045-1009

Name: Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header 10 Contact 3 mm Pitch 2 Row Shrouded 43045-1009
Brand: Molex
SKU: 206468
Price: 2.77 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	Mexico
Voltage	250V
Brand	Molex
Orientation	Right Angle
Current	5A
Mount Type	Surface
Contact Material	Brass
Series	Micro-Fit 3.0
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	3mm
Contact Plating	Tin
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Mating Pin Length	3mm

Key Features

Features 10 male contacts arranged in 2 rows with a 3 mm pitch.
Shrouded design enhances safety and prevents accidental disconnection.
Supports a current rating of 5A and voltage rating of 250V.
Constructed with brass contacts plated with tin for reliable conductivity.
Equipped with solder tabs for secure surface mounting on PCBs.
Operates reliably between -40°C and 125°C.
Includes positive latching mechanism for secure mating.
Housing made from UL 94V-0 liquid crystal polymer, resistant to IR reflow temperatures up to 265°C.

Product Description

Molex 43045-1009 Micro-Fit 3.0 Series Right Angle Surface PCB Header is a compact power connector solution providing a reliable low to mid-range power distribution with a small footprint.

This PCB header features 10 male contacts arranged in two rows with a 3 mm pitch, suitable for wire-to-board connections. The contacts are made of brass with tin plating, ensuring dependable electrical conductivity and durability.

The shrouded housing prevents accidental disconnects and provides secure mating through its positive latching locking ramp design. It is manufactured from high-temperature UL 94V-0 liquid crystal polymer capable of withstanding the 265°C heat of IR reflow soldering, allowing for surface mount technology (SMT) assembly incorporating solder tabs for enhanced mechanical stability.

Rated for 5A current and 250V voltage, this connector supports industrial, military COTS, solar power systems, consumer appliances such as dryers and refrigerators, data communications including routers and servers, medical devices, telecommunications, and gaming terminals.

Features 10 male contacts arranged in 2 rows with a 3 mm pitch. Shrouded design enhances safety and prevents accidental disconnection. Supports a current rating of 5A and voltage rating of 250V. Constructed with brass contacts plated with tin for reliable conductivity.

Equipped with solder tabs for secure surface mounting on PCBs. Operates reliably between -40°C and 125°C. Includes positive latching mechanism for secure mating. Housing made from UL 94V-0 liquid crystal polymer, resistant to IR reflow temperatures up to 265°C.

Suitable for applications in military, solar power, consumer appliances, data communications, medical, telecommunications, and gaming equipment.

This component is manufactured in Mexico and supplied in new condition, ensuring quality compliance for demanding industrial electronics and power distribution applications. Explore more Molex connectors and related PCB components at EnvMart.
