Molex KK 508 Series Straight Through Hole Pin Header 4 Contacts 5.08 mm Pitch 1 Row Unshrouded 10-08-1041

Molex 10-08-1041 KK 508 Series Straight Through Hole Pin Header is a versatile and robust connector component designed for industrial and electronic applications. This pin header features 4 contacts arranged in a single row with a 5.08 mm pitch commonly used for board-to-board and wire-to-board connections.

Its housing is constructed from high-quality nylon providing durability and insulation. The brass contacts are male type with tin plating ensuring reliable electrical conductivity and corrosion resistance. This header supports a maximum current of 7 amperes and operates efficiently at voltages up to 250 volts, making it suitable for various power and signal transmission applications.

The component is designed for through hole mounting with solder termination offering secure mechanical and electrical connections on printed circuit boards. It performs reliably within an operating temperature range of -40°C to 80°C, accommodating demanding industrial environments.

The tail pin length of 3.94 millimeters ensures adequate insertion depth for dependable connections. This header mates with Molex 3001 and 5058 Series housings as well as 3002 Series PCB connectors, facilitating flexible system design.

Ideal for applications including electronics manufacturing, industrial machinery, automotive electronics, and communication equipment, the KK series provides economic and effective interconnection with increased creepage and clearance distance requirements due to its 5.08 mm pitch. It utilizes the same crimp contacts and tooling as the 3.96 mm pitch variants for manufacturing convenience.

This pin header features a straight orientation and is unshrouded for easy mating. It has a single row configuration with 4 male brass contacts plated with tin. The housing is made from durable nylon material suitable for industrial usage.

Rated for a maximum current of 7A and voltage up to 250V for reliable performance. Supports through-hole mount type and solder termination for secure connections. Operates efficiently within a temperature range from -40°C to 80°C.

Contact tail pin length measures 3.94 mm for proper insertion depth. Compatible with Molex 3001, 3002, 3003 and 5058 Series connectors and housings. Widely used in electronics manufacturing, automotive, industrial machinery, and communication equipment.

The KK series offers economical and simple wire-to-board and board-to-board interconnection solutions. Explore our wide range of industrial connectors and electronics components at EnvMart for reliable and high-quality products suitable for professional applications.
